Prosoft RLX2-IHW High Power Industrial Hotspot

Prosoft RLX2-IHW High Power Industrial Hotspot

PROSOFT TECHNOLOGY
INDUSTRIAL WIRELESS
RLX2-IHW

WIRELESS ETHERNET
Reliable industrial network connectivity
TECHNICAL PROFILE
Wireless communication at a glance
STANDARD
802.11
a / b / g
Supported wireless standards
DATA RATE
54
Mbps
Maximum RF data rate
ROAMING
<10
ms
Fast access point switchover
CONTACT OUR TEAM
Miya Zheng
Sales Manager
SCAN TO CONNECT
 INTERNATIONAL DELIVERY ON THE DAY
QUICK RESPONSE SUPPORT
 INTERCONTINENTAL COOPERATION NETWORK
PROSOFT TECHNOLOGY / INDUSTRIAL WIRELESS
RLX2-IHW

802.11abg Industrial Hotspot
Industrial-grade dual-band wireless Ethernet radio for fixed infrastructure, mobile equipment and long-range links up to 5 mi / 8 km under suitable path and antenna conditions.
54 Mbps
PRODUCT OVERVIEW
Secure wireless Ethernet for industrial assets
RLX2-IHW operates in 2.4 GHz and 5 GHz bands with data rates up to 54 Mbps. It supports access point, repeater and client-style industrial wireless roles, secure WPA2/AES networking, VLAN segmentation, QoS, radio diagnostics and fast roaming for moving machinery.
TECHNICAL PROFILE
Exact Configuration
Wireless standards IEEE 802.11a/b/g; 802.11i security
Frequency bands 2.4 GHz and 5 GHz, country dependent
Maximum RF data rate 54 Mbps
Link distance Up to 5 mi / 8 km with suitable antennas and clear path
Security WPA2 Personal/Enterprise, 128-bit AES, RADIUS
Traffic control VLAN, QoS, IGMP snooping and packet filtering
Mobility Ultra-Fast Roaming under 10 ms
Power option Power over Ethernet supported
Recovery Configuration backup on microSD
Diagnostics EtherNet/IP or Modbus access to radio diagnostics
WIRELESS SELECTION PATH
Choose the network architecture before the radio
01 / LEGACY COMPATIBILITY
RLX2-IHW
Strength: dual-band 802.11a/b/g support, industrial security and links up to 54 Mbps.
Use when: the installed network depends on 802.11a/b/g compatibility or moderate SCADA traffic.
02 / HIGHER THROUGHPUT
RLX2-IHNF
Strength: 802.11n performance for faster backbones and greater bandwidth demand.
Use when: network growth, video or larger data loads exceed the practical role of RLX2-IHW.
03 / FIXED PATH
Wired Ethernet
Strength: predictable physical path without RF interference or roaming design.
Use when: cabling is practical and the asset does not move, rotate or cross a long open span.
Decision checkpoint: verify frequency regulations, client standards, antenna system, Fresnel clearance, roaming demand and multicast traffic before purchase.
SELECTION VALUE
RLX2 wireless choices by speed and application
RLX2-IHW
Advantage: proven 802.11abg compatibility, dual-band operation and long-range industrial links up to 54 Mbps.
Use when: installed networks depend on 802.11a/b/g radios or throughput demand is moderate.
RLX2-IHNF
Advantage: 802.11n capability and higher throughput for faster industrial wireless backbones.
Use when: bandwidth, newer client support or network growth justifies the fast-radio platform.
Wired industrial Ethernet
Advantage: deterministic physical path without RF planning.
Use when: cabling is practical and mobility, rotating assets or long spans are not present.
◆ AMIKON SUPPLY NETWORK
20 Years Supporting Industrial Automation
◎ GLOBAL DELIVERY
◉
Responsive Team
Part-number matching and quotation coordination for global maintenance teams.
⇄
Supply Process
1 Match → 2 Check
3 Pack → 4 Dispatch
Broad automation inventory, responsive quotations, worldwide coordination and a 12-month warranty.
☑
Warehouse Delivery
Coordinated packing and international dispatch for urgent automation requirements.
✓ Factory-sealed options ◉ Fast response ⇄ Intercontinental network ◆ T/T accepted
GLOBAL SUPPORT TEAM
AMIKON | 20 Years of Automation Supply
Since 2005, AMIKON has supported industrial maintenance teams with broad automation inventory, international delivery, responsive quotations and a 12-month warranty.
Factory-sealed options Worldwide coordination
Fast response T/T accepted
WAREHOUSE & DELIVERY
Return support: report a concern within seven days. Keep the item in its original condition and state the return reason. Buyer-arranged freight applies; refund or replacement review starts after receipt.
BUYER DECISION FAQ
Five Checks Before Ordering RLX2-IHW
01 Does RLX2-IHW suit an existing 802.11n-only design? Not as the primary choice. RLX2-IHW is an 802.11a/b/g platform; verify client compatibility or consider RLX2-IHNF when 802.11n is required.
02 Can RLX2-IHW carry EtherNet/IP multicast traffic? Yes, but configure IGMP snooping, packet filtering, QoS and RF channel planning to control multicast loading and latency.
03 What determines whether the 8 km claim is achievable? Antenna gain, cable loss, regulatory power limits, Fresnel-zone clearance, interference, mounting height and link margin must all be engineered.
04 How should a replacement RLX2-IHW be commissioned quickly? Preserve the approved radio configuration on microSD, then verify firmware, region, channel plan, IP addressing, security credentials and antenna connections.
05 When is PoE preferable for RLX2-IHW? Use PoE when one Ethernet run simplifies installation, provided the injector, cable length, grounding and hazardous-area practices match the site.
Confirm the exact configuration before purchase
Send the complete part number, application, installed hardware and quantity.
REQUEST A QUOTE
