Motorola MVME162-520 embedded VME controller

Motorola MVME162-520
Motorola MVME162-520
Motorola MVME162-520

Motorola MVME162-520 embedded VME controller

Calculate shipping
Quotation Request
MOTOROLA / EMBEDDED COMPUTING
MVME162
520

32-bit VME controller architecture combining MC68040 processing, onboard memory and IndustryPack expansion.
◉   PROCESS    ◉   EXPAND


M
CORE
32 MHz
8 MB DRAM
4 × IP
MC68040
32-bit processing
512 KB SRAM
1 MB Flash
2 serial ports
VMEbus architecture
AMIKON INDUSTRIAL SUPPORT
We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.
CONTACT MIYA
✦   Sales manager: Miya zheng ✉   sales@amikon.cn ☎   WhatsApp / 86-18020776792
VME · CPU · MEMORY · IP
MOTOROLA MVME162-520 PRODUCT SYSTEM AMIKON CONTACT FAQ MODELS


32-BIT EMBEDDED VME CONTROLLER
MVME162-520
32 MHz MC68040 · 8 MB DRAM · 4 DMA IndustryPack Sites
The MVME162-520 is an embedded VME controller configuration centered on the 32 MHz MC68040 processor. Its 8 MB onboard DRAM, 512 KB battery-backed SRAM, Flash storage, two serial interfaces and four IndustryPack sites form a compact controller platform for modular VME systems.
◎
Configuration fingerprint
Processor MC68040 · 32 MHz
DRAM 8 MB
SRAM 512 KB battery-backed
Flash 1 MB
IndustryPack 4 DMA-capable sites
Serial 2 ports
VMEbus A16 / A24 / A32 · D8 / D16 / D32
A controller built around expansion Four IndustryPack interfaces give the MVME162-520 a modular I/O path, while the VMEbus interface connects the controller to the wider chassis. The standard family architecture also includes Flash, battery-backed SRAM, NVRAM/time-of-day functions and timers.
Processing core
The MC68040 provides the 32-bit processor foundation at a 32 MHz clock rate for the -520 configuration.
Memory architecture
8 MB DRAM is combined with 512 KB battery-backed SRAM and 1 MB Flash, creating separate working and persistent storage resources.
Modular I/O
Four DMA IndustryPack sites allow application-specific I/O expansion without changing the basic VME controller architecture.
MVME162 CONFIGURATION RELATIONSHIP
The suffix determines processor, memory and integrated peripheral configuration.
Model CPU DRAM IndustryPack Serial Extra interface
MVME162-510 MC68040 · 32 MHz 4 MB 4 DMA 2 —
MVME162-520 MC68040 · 32 MHz 8 MB 4 DMA 2 —
MVME162-521 MC68040 · 32 MHz 8 MB 4 DMA 2 SCSI
MVME162-522 MC68040 · 32 MHz 8 MB 4 DMA 2 Ethernet
MVME162-523 MC68040 · 32 MHz 8 MB 4 DMA 2 SCSI + Ethernet
MVME162-530 MC68040 · 32 MHz 16 MB 4 DMA 2 —
Selection point: MVME162-520 is the 8 MB configuration without the additional SCSI or Ethernet options associated with -521/-522/-523. If the application requires more memory while keeping the same basic peripheral arrangement, MVME162-530 moves to 16 MB.




◎
AMIKON STOCK NETWORK
Amikon's large stock is the core of our supply.
Our large stock of industrial products is ready for delivery, which is the core of our supply. It contains more than 400,000 electronic products, such as PLC, HMI, drivers, servo and CNC devices, IPC and PG.
400,000+ industrial electronic products
New, current and discontinued ranges
Strategic purchasing based on demand


READY FOR LEGACY AND CURRENT DEMANDS Whether new or out of production, from the smallest module to the complete configuration. We have products that have not been available for many years, the latest technology and all other products in between.

STOCK READY
 Market insight, technology development and customer demand enable us to buy strategically, so we seldom need to transfer business. If items happen to be out of stock, we will search our preferred supplier network for you.
CONTACT AMIKON
Ask for MVME162-520 availability, configuration matching or quotation.
Miya Zheng · Sales Manager
Phone / WhatsApp: +86 180 2077 6792
 EMAIL SALES WHATSAPP
Delivery
3–5 days		 Warranty
12 months		 Delivery way
FedEx / DHL / UPS / TNT / EMS		 Payment
T/T
Return / replacement: Please contact us within 7 days after receipt if there is an issue. Returned items should be in original condition with a specific reason. After receipt of the return, we will arrange a return or replacement. The buyer covers return shipping costs.
MVME162-520 · BUYER FAQ
Q1. What specifically distinguishes MVME162-520 from MVME162-510?
Both are 32 MHz MC68040 configurations with four DMA IndustryPack sites and two serial interfaces, but MVME162-520 carries 8 MB DRAM while MVME162-510 carries 4 MB.
Q2. If an existing system needs SCSI, is MVME162-520 the direct configuration to request?
No. The -520 configuration is the 8 MB version without the dedicated SCSI option represented by MVME162-521. If SCSI is part of the required controller configuration, the -521 family member should be considered instead.
Q3. Can MVME162-520 provide application-specific I/O without replacing the controller?
Its four IndustryPack sites are intended for modular I/O expansion. This allows the controller platform to be paired with suitable IndustryPack modules while retaining the same processor and VMEbus base.
Q4. Why does MVME162-520 include both DRAM and battery-backed SRAM?
The 8 MB DRAM provides working memory, while the 512 KB battery-backed SRAM provides a separate retained-memory resource. The family also provides Flash and battery-backed time-of-day/NVRAM functions.
Q5. What should be matched before using MVME162-520 as a replacement?
Match the 32 MHz MC68040 configuration, 8 MB DRAM requirement, four IndustryPack sites, two serial interfaces, VMEbus addressing/data-width requirements, firmware expectations and the chassis/backplane arrangement. Also verify whether the existing application actually requires SCSI or Ethernet, because those are separate MVME162 configurations.
