HIMax COMMUNICATION PLATFORM
X-COM 01
Communication Module for HIMax
|
|
01
|
A communication-focused HIMax module
The HIMA X-COM 01 is designed for communication within the HIMax programmable electronic system. It supports communication through Ethernet and optional fieldbus interfaces and can transport safety-related protocols as part of a configured HIMax architecture.
SYSTEM ROLE Communication module / HIMax system networking / Ethernet and optional fieldbus connectivity
|
MODULE PROFILE
Family
HIMax Type
Communication Module Protection
IP20 |
|
01
ETHERNET NETWORKING
Four Ethernet switch ports are provided through RJ-45 connections.
|
02
FIELD BUS OPTIONS
Up to two fieldbus interfaces can be provided through manufacturer-installed fieldbus submodules.
|
03
NETWORK FLEXIBILITY
Ethernet ports support 10BASE-T / 100BASE-TX with half- and full-duplex operation.
|
04
CONFIGURATION
Ethernet IP addressing and subnet configuration are freely configurable within applicable network rules.
|
|
TECHNICAL DATA
X-COM 01
The communication module operates as part of a HIMax system and provides Ethernet connectivity, with fieldbus connectivity available according to the selected module configuration.
APPLICATION POSITION
HIMax programmable electronic system
|
|
|
PROCESSOR
X-CPU 01 / X-CPU 31
HIMax processor modules
|
→ |
COMMUNICATION
X-COM 01
Ethernet + optional fieldbus
|
→ |
SYSTEM I/O
HIMax I/O Modules
Configured process interface
|
|
DIRECT SUPPORT
Need X-COM 01?
Send the required part details and destination for a quotation.
|
|
DELIVERY
3–5 Days |
WARRANTY
12 Months |
PACKAGING
Brand New |
PAYMENT
T/T |
SHIPPING
Global Delivery |
| 01 |
Can X-COM 01 be ordered as a complete communication solution without fieldbus submodules?
Yes. X-COM 01 is the communication-module version without fieldbus submodules. If a project requires fieldbus connectivity, the corresponding fieldbus submodule configuration must be specified, and the resulting module designation changes accordingly.
|
| 02 |
What should be checked before replacing an existing X-COM 01 in a HIMax installation?
Check the module designation, hardware and software revision requirements, connector-board configuration, installed fieldbus options, and the communication functions required by the existing application. A replacement should match the actual HIMax configuration rather than relying on the base model name alone.
|
| 03 |
Does X-COM 01 provide the same communication configuration as X-COM 01 E?
Not necessarily. HIMA lists X-COM 01 and X-COM 01 E as distinct communication-module versions. Their connector arrangements and memory/configuration characteristics should therefore be checked against the installed system before substitution.
|
| 04 |
Is the X-COM 01 connector board included when purchasing the communication module?
The X-COM 01 module forms a functional unit with its connector board, but the connector board is specified as a separate component. For procurement, the existing connector-board type should therefore be confirmed before ordering a replacement module.
|
| 05 |
When is X-COM 01 a practical replacement choice for a HIMax communication position?
It is applicable when the existing HIMax architecture requires the X-COM 01 communication role, including Ethernet networking and the required safety-related or standard communication functions. The exact module configuration, fieldbus options and system revision should be matched before replacement.
|
|
