HIMA · TERMINAL CONNECTION
H 7015A
Terminal Module with ELCO 8016 Vario Interface
Part Number: 992701503
H 7015A is a HIMA terminal module designed to organize the interface between HIMA I/O assemblies and external cabinet wiring. Its 56-pin ELCO 8016 Vario connection provides a defined interface for system cabling, while the module can be used with H 7018 and BV 7201 in cabinet-to-marshalling-cabinet wiring arrangements.
A cabinet-side termination interface designed around the HIMA I/O connection architecture.
|
Inventory Instance
|
| ELCO 8016 | Code 1-1 |
| Terminal module | HIMA I/O interface |
|
INTERFACE ARCHITECTURE
The Connection Path
H 7015A sits at the termination side of the HIMA I/O connection arrangement. Its interface is built around the ELCO 8016 Vario connection and can be extended through the H 7018 / BV 7201 combination. |
The H 7015A / BV 7201 / H 7018 arrangement is intended for fast and efficient plug-and-play wiring between a PLC cabinet and a marshalling cabinet.
|
| Model | H 7015A | Part Number | 992701503 |
| Product Type | Terminal Module | Manufacturer | HIMA |
| Main Interface | ELCO 8016 Vario plug | Plug Code | 1-1 |
| ELCO Connection | 1 × 56-pin | Terminal Range | A1 ... C32 |
| Phoenix Header | 8-pin | WAGO Interface | 739 · 16-pin |
| Related Module | H 7018 | Connection Cable | BV 7201 |
| Typical Role | Cabinet / marshalling termination | Connection Concept | Plug-and-play cabinet wiring |
|
CONNECTION LOGIC
One Module, Several Wiring Routes
|
The H 7015A is more than a passive label point in the cabinet. Its defined terminal arrangement lets the HIMA I/O side be carried into external wiring structures while keeping the connection scheme organized around the ELCO interface.
|
|
FIELD APPLICATION
Where H 7015A Matters
|
H 7015A is associated with the HIMA I/O termination architecture used in control cabinets and marshalling cabinets. In a maintenance situation, engineers are likely to search for this exact terminal module when a cabinet wiring interface, ELCO connection, marshalling path or associated terminal assembly has to be restored without changing the established I/O arrangement.
|
|
