| GE FANUC / QUICKPANEL VIEW |
IC754VKI06MTD
QuickPanel View Starter Kit
6-inch Monochrome Intermediate · 24 VDC
|
6"
DISPLAY CLASS
|
320×240
DISPLAY RESOLUTION
|
24VDC
POWER CLASS
|
|
|
PRODUCT ID
IC754VKI06MTD
|
●
|
QuickPanel View starter kit
|
|
●
|
6-inch monochrome intermediate display
|
|
●
|
24 VDC operating class
|
|
|
|
|
|
|
CORE PARAMETERS
Technical Profile
| Display |
6-inch class monochrome display |
| Resolution |
320 × 240 pixels |
| Memory |
32 MB DRAM; expandable to 96 MB |
| Serial Interface |
COM #1: RS232 / RS485 |
| Ethernet |
10/100 Mbps |
|
|
AT A GLANCE
|
01
|
Intermediate View Platform
Designed as part of the QuickPanel View family.
|
|
02
|
Compact Operator Display
A 6-inch monochrome operator interface format.
|
|
03
|
Network Connectivity
Ethernet and serial communication capabilities.
|
|
|
|
|
◆
|
CONTROL FLOOR USE
Where This Panel Fits
The IC754VKI06MTD belongs to the QuickPanel View operator-interface family and is suited to applications where operators need a compact monochrome panel for machine or process interaction. Its 320 × 240 display format, serial connectivity and Ethernet capability support communication between the operator interface and the surrounding control environment.
When an existing panel stops displaying the operator screen, loses communication with the control system, or can no longer support normal operator interaction, the exact part number becomes important. Using the wrong display family or interface combination can introduce additional commissioning work and extend equipment downtime.
|
|
|
◈
Operator Interface
Compact QuickPanel View architecture for operator interaction.
|
|
|
◉
Communication
RS232/RS485 serial communication with Ethernet connectivity.
|
|
|
◇
Compact Display
5.7-inch diagonal display class with 320 × 240 resolution.
|
|
|
|
Need a Price for IC754VKI06MTD?
Send the exact part number together with your quantity and destination. We can check the current supply option and prepare a quotation.
|
REQUEST PRICE |
|
|
FREQUENT QUESTIONS
IC754VKI06MTD FAQ
| 01 |
Can IC754VKI06MTD be treated as a direct replacement for every 6-inch QuickPanel View unit?
No. A matching screen size alone does not establish replacement compatibility. The display class, memory configuration, communications interfaces, software environment and application configuration should all be checked before substitution.
|
| 02 |
What makes the intermediate version different from a basic QuickPanel View configuration?
The IC754VKI06MTD is identified as the 6-inch monochrome Intermediate starter-kit configuration. It should therefore be matched against the existing application's required hardware and communication arrangement rather than selected only by screen size.
|
| 03 |
Which communication interfaces should be checked before installing a replacement?
The existing installation should be checked for the required serial interface arrangement and Ethernet connection. The IC754VKI06MTD configuration is associated with RS232/RS485 serial communication and 10/100 Mbps Ethernet.
|
| 04 |
What should be checked when replacing an IC754VKI06MTD in an operating machine?
Confirm the exact part number, display type, power requirement, communication connections and application configuration before removing the existing unit. A mismatch can turn a simple panel replacement into additional configuration and commissioning work.
|
| 05 |
Why is the exact part number important when sourcing an IC754VKI06MTD replacement?
The IC754VKI06MTD identifies a specific QuickPanel View starter-kit configuration. Confirming the complete part number helps prevent confusion with other 6-inch Basic, Intermediate, STN or Loaded configurations in the same product family.
|
|
|
