| QUICKPANEL VIEW BASIC SERIES |
| GE INDUSTRIAL OPERATOR INTERFACE |
| IC754VGB06CTD |
| 6-inch TFT Color Touch Operator Interface |
|
|
|
| PRODUCT SNAPSHOT |
|
DISPLAY
6-inch TFT
|
TOUCH
Resistive
|
|
RESOLUTION
320 × 240
|
INPUT
12–30 VDC
|
| Flat-bezel QuickPanel View configuration |
|
|
|
01
|
Technical Profile
Core characteristics of IC754VGB06CTD
|
|
|
01
DISPLAY
TFT Color
6-inch class display for operator visualization.
|
02
TOUCH INPUT
Resistive
Touch-based operator interaction for panel operation.
|
03
IMAGE FORMAT
320 × 240
Quarter-VGA class display resolution.
|
04
POWER
12–30 VDC
DC input range suited to industrial control panel environments.
|
|
| Specification Matrix IC754VGB06CTD |
| Parameter |
IC754VGB06CTD |
| Product family |
QuickPanel View |
| Model class |
Basic |
| Display |
6-inch TFT color display |
| Display resolution |
320 × 240 pixels |
| Touch technology |
Resistive touchscreen |
| Power input |
12–30 VDC |
| Bezel configuration |
Flat bezel |
|
|
|
02
|
Operator-Facing Control Environment
The IC754VGB06CTD belongs to the QuickPanel View family and combines a compact TFT display with touch-based operator interaction. Its role is centered on presenting machine or process screens and allowing operators to work directly from the panel interface.
|
WHEN IT IS USED
Machine and process operator panels
Suitable where a compact operator interface is required for visualization and touch interaction.
|
WHEN SEARCHES BEGIN
Display or touch-interface faults
Typical replacement searches can arise when the existing operator panel no longer provides reliable visual or touch interaction.
|
WHY IT MATTERS
Operator visibility and machine access
A failed operator terminal can make normal machine interaction difficult and may extend troubleshooting or restart time.
|
|
|
|
QUICK PRICE REQUEST
Need a price for IC754VGB06CTD?
Send the part number, quantity, destination, required date and machine/system. This allows the quotation to be prepared around your actual requirement.
|
SALES MANAGER
Miya Zheng
|
|
| Practical FAQ Selection • Compatibility • Replacement |
|
01 How does the IC754VGB06CTD fit into a QuickPanel View application?
It is a Basic QuickPanel View operator interface with a 6-inch TFT color display, touch input and a flat bezel configuration.
|
| |
|
02 What should be checked before replacing an existing unit?
Check the exact part number, display class, touch arrangement, bezel configuration, power requirement and the existing panel cutout before installation.
|
| |
|
03 Why can an incorrect replacement create commissioning risk?
A replacement with a different display, touch arrangement, power requirement or mechanical configuration may require additional engineering work and can affect the existing operator-panel installation.
|
| |
|
04 What makes the 6-inch TFT version different from a mono display?
The IC754VGB06CTD uses a color TFT display, while QuickPanel View variants in the same family were also offered with different display technologies and configurations. The exact part number should therefore be matched before replacement.
|
| |
|
05 What should be confirmed when sourcing a replacement for a long-running machine?
Confirm the complete part number rather than matching only the screen size. Display type, touch technology, bezel design, electrical requirements and the existing machine configuration should all be checked before the replacement is selected.
|
|
|
