GE PACSYSTEMS™ RX3i
IC695ALG708
8-Channel Analog Current / Voltage Output Module
Non-isolated configurable analog output for PACSystems RX3i control applications
|
ANALOG OUT
708
RX3i · 8 CHANNEL
CURRENT / VOLTAGE
|
|
DIRECT INDUSTRIAL SUPPORT
Need IC695ALG708?
Send us the part number, quantity, destination, required date and machine/system details for a quotation.
|
Sales Manager: Miya Zheng
Email: sales@amikon.cn
Phone / WhatsApp: +86 180 2077 6792
|
|
01 · Can IC695ALG708 replace an existing RX3i analog output module when the field devices use 4–20 mA signals?
It can be used for 4–20 mA output applications, but the replacement should be checked against the existing channel configuration, terminal-block arrangement, external field-power wiring and whether the application requires isolated outputs. IC695ALG708 is a non-isolated output module.
|
02 · Why does an IC695ALG708 installation require an external 24 VDC field supply?
The analog output circuitry receives field power from an external 24 VDC source. The applicable supply range is 19.2–30 VDC, with 24 VDC nominal. This field supply must be connected directly to the module terminal block rather than through the RX3i Universal Backplane TB1 connector.
|
|
03 · Is IC695ALG708 the appropriate RX3i choice when output isolation is required?
No. IC695ALG708 provides non-isolated analog outputs. Within the same RX3i analog-output family, IC695ALG808 is the isolated 8-channel current/voltage output option. The required isolation arrangement should therefore be confirmed before selecting a replacement.
|
04 · What should be verified in the controller before installing IC695ALG708?
The RX3i CPU should meet the module's firmware requirement of version 3.0 or later, and the configuration environment should support the module. Existing channel ranges, output behavior, scaling, alarms and terminal-block type should also be reviewed before the replacement is commissioned.
|
|
05 · When would IC695ALG728 be considered instead of IC695ALG708?
IC695ALG728 is the 8-channel member of the same analog-output family that adds HART communication capability. IC695ALG708 is the non-HART version. If the existing process architecture requires HART communication on applicable 4–20 mA channels, the ALG728 configuration should be considered rather than treating ALG708 as a direct functional equivalent.
|
|
|
