GE IC695ACC400-CA RX3i CPU Energy Pack with Conformal-Coated Configuration
|
PACSYSTEMS RX3i / ENERGY BACKUP
IC695ACC400-CA
RX3i CPU Energy Pack with Conformal-Coated Configuration
The IC695ACC400 family is an RX3i Energy Pack designed to support compatible RX3i CPU operation during loss of system power. Its role is to provide temporary energy support so the controller can preserve user memory by writing the contents to non-volatile storage.
|
IC695ACC400-CA
|
|
01 / PRODUCT ARCHITECTURE
Designed Around RX3i Power-Loss Protection
IC695ACC400-CA belongs to the PACSystems RX3i Energy Pack family. The Energy Pack is positioned beside an RX3i module rather than occupying a conventional backplane slot, allowing the backup function to be integrated with the controller installation without consuming another backplane position.
During normal operation, the Energy Pack receives charging power through the dedicated connection from the compatible CPU. When system power is lost, the stored energy supports the CPU long enough for user memory contents to be transferred to non-volatile flash storage.
The IC695ACC400 configuration is associated with the RX3i CPE305 and CPE310 CPU platform. The Energy Pack connects to the CPU using the IC695CBL001 Energy Pack cable.
|
FUNCTIONAL CORE
Power Loss → Memory Preservation
◌ Normal operation: Energy Pack charges from the RX3i controller.
◌ Power interruption: backup energy becomes available to the CPU.
◌ Preservation phase: CPU writes user memory to non-volatile flash.
◌ Recovery: controller can retain the stored user-memory contents.
|
|
CATALOG NUMBER
IC695ACC400-CA
|
PRODUCT FAMILY
PACSystems RX3i
|
FUNCTION
CPU Energy Backup
|
CONFIGURATION
Conformal Coated
|
|
COMPATIBLE CPU PLATFORM
CPE305 / CPE310
|
CONNECTION
IC695CBL001
|
MOUNTING CONCEPT
Side-Mounted
|
BACKPLANE USAGE
No Dedicated Slot
|
|
DIMENSIONS
140 × 124 × 25.4 mm
5.5 × 4.87 × 1 in
|
OPERATING TEMPERATURE
0 to 60°C
32 to 140°F
|
BACKUP PURPOSE
User Memory Preservation
|
COATING
Conformal-Coated Version
|
|
◌
What the Energy Pack Protects
The primary purpose is not to operate field I/O independently. Instead, the Energy Pack supports the controller during a power-loss event so the CPU has time to preserve user memory in non-volatile storage.
This makes the component particularly relevant where controller state retention is important and an unexpected power interruption must not immediately remove the working memory contents of the CPU.
|
◌
OPERATING SEQUENCE
|
|
CPU
CPE305 / CPE310
The compatible RX3i CPU performs the controller processing and manages the transition associated with a system power-loss event.
Core relationship: controller ↔ Energy Pack
|
ENERGY PACK
IC695ACC400-CA
Provides the temporary energy support required for the compatible CPU to preserve user memory during loss of system power.
Core relationship: backup energy ↔ CPU memory preservation
|
CABLE
IC695CBL001
The Energy Pack uses the dedicated IC695CBL001 cable to connect with the compatible CPU.
Core relationship: physical and electrical connection
|
|
IC695ACC400-CA
Conformal-coated RX3i CPU Energy Pack configuration intended for compatible CPE305/CPE310 applications.
|
IC695ACC400
Same core Energy Pack family and power-loss memory-preservation function without the -CA configuration designation.
|
IC695ACC402 Family
A different RX3i Energy Pack generation with a separate controller connection architecture; it should not be treated as a direct interchange for IC695ACC400-CA.
|
|
03 / DIRECT INQUIRY
Need IC695ACC400-CA?
Send the part number, required quantity, destination and required date. For system-matching requests, you can also provide the controller or machine information so the order can be checked against the intended application.
|
Inquiry Checklist
|
|
ORDER SUPPORT
Delivery · Warranty · Packaging · Payment
|
Return & Replacement
01 · Contact us within 7 days after receiving the items if an issue occurs.
02 · Returned items should remain in original condition with the specific reason stated.
03 · A return or replacement can be arranged after the returned items are received.
04 · Return shipping costs are the buyer's responsibility.
|
||||||
|
01. Can IC695ACC400-CA be used with an RX3i CPE305 or CPE310 replacement project?
Yes. The IC695ACC400 Energy Pack is intended for the RX3i CPE305 and CPE310 CPU platform. For a replacement project, the CPU model, Energy Pack configuration and required cable should be checked together rather than treating the Energy Pack as an independent CPU component.
|
02. Does IC695ACC400-CA require a dedicated RX3i backplane slot?
No. The Energy Pack mounts on the left side of an RX3i module and is connected to the CPU by the dedicated cable. This side-mounted arrangement avoids consuming an additional backplane slot for the Energy Pack itself.
|
|
03. What is the practical difference between IC695ACC400-CA and IC695ACC400?
Both belong to the RX3i IC695ACC400 Energy Pack family and perform the same core CPU memory-preservation function. The “-CA” designation identifies the conformal-coated configuration, so the exact configuration should be matched to the installed system and purchasing requirement.
|
04. Is IC695ACC400-CA interchangeable with the newer IC695ACC402 Energy Pack?
They should not be treated as automatic drop-in replacements. IC695ACC402 belongs to a different Energy Pack generation with a different controller connection architecture. For an existing IC695ACC400-CA installation, the installed CPU and connection method should be verified before considering another Energy Pack family.
|
|
05. What should be checked before ordering IC695ACC400-CA for a shutdown-sensitive RX3i system?
Confirm the installed CPU model, verify that the system uses the compatible CPE305/CPE310 platform, check the Energy Pack connection requirement for IC695CBL001, and match the requested conformal-coated configuration. For an installed system, the complete controller arrangement should be considered rather than ordering the Energy Pack only by physical appearance.
|
|
