| GE / SERIES 90-30 MOTION CONTROL | OverviewSpecificationsIntegrationRelated ModelsFAQ |
IC693APU301M is an intelligent VersaMax analog input module for four independent RTD or resistance measurements. It supplies sensor excitation, performs high-resolution conversion and reports wiring and range diagnostics to the host controller.
REQUEST PRICE AND LEAD TIME| SERIES
Series 90-30
|
INPUT
One Servo Axis
|
RESOLUTION
1 ms Loop
|
POWER
Motion Mate
|
| Module type | Motion Mate Axis Positioning Module | Catalog revision | IC693APU301M |
| Controlled axes | One | Servo-loop update | 1 ms |
| Operating mode 1 | Standard positioning | Operating mode 2 | Follower electronic gearing |
| Motion programs | Up to 10 stored programs | PLC integration | Automatic exchange with CPU tables |
| Slot width | Single Series 90-30 slot | Baseplate support | CPU, expansion or remote baseplate |
| Embedded CPU systems | Up to 3 APM modules | Modular CPU systems | Up to 8 APM modules, maximum 3 per baseplate |
| Drive interface | Analog servo command and machine signals | Feedback | Encoder and axis feedback through front connectors |
| Status | Front module and axis LEDs | Replacement check | Programs, scaling, limits, cables and drive tuning |
| 01 | PLC and operator command The machine sequence selects a stored motion action and supplies operating conditions. |
| 02 | APM motion engine The module calculates the one-axis trajectory independently of the normal PLC scan. |
| 03 | Drive and feedback interface Analog servo commands, encoder feedback, enable and machine signals close the motion loop. |
| 04 | Machine axis The motor and mechanism execute position, velocity or follower movement within configured limits. |
| How many axes can it control?
IC693APU301 controls one servo axis. |
What is follower mode?
It provides electronic gearing for master and slave motion. |
| Does motion depend on the PLC scan?
The module executes motion locally while exchanging data with the CPU. |
Can IC693APU302 replace it?
Do not assume so; axis count, configuration and connections differ. |
| What must be preserved before replacement?
Save programs, scaling, home settings, limits, cable assignments and drive tuning.
|
|
Include IC693APU301M, CPU type, drive and feedback hardware, cable numbers, quantity, condition and destination.
CONTACT THE AUTOMATION TEAM|
