GE IC670MDL730 Field Control Discrete Input Module

GE IC670MDL730
GE IC670MDL730
GE IC670MDL730

GE IC670MDL730 Field Control Discrete Input Module

Calculate shipping
Quotation Request
GE FIELD CONTROL

PRODUCT MODEL
IC670MDL730
  Field Control I/O Module

GE Field Control module designation for industrial I/O applications.
KEY PARAMETERS
01
Product Family
Field Control

02
I/O Platform
Field Control I/O

03
Module Series
IC670 Series
CONTACT

SALES MANAGER
Miya Zheng
EMAIL
sales@amikon.cn
PHONE / WHATSAPP
86-18020776792

Please contact us for
availability and quotation.
GE FIELD CONTROL Overview Specifications Application FAQ Contact
FIELD CONTROL · OUTPUT
IC670MDL730
24 VDC positive logic discrete output module with electronic short-circuit and overcurrent protection.
01 8 discrete outputs
Single output group

02 24 VDC nominal
18–30 VDC user input

03 2 A maximum / point
8 A maximum / module
TECHNICAL SNAPSHOT

Output Type
Discrete
Logic
Positive
User Voltage
18–30 VDC
Nominal
24 VDC
Load / Point
2.0 A max.
Module Load
8 A max.
On Response
500 μs max.
Off Response
500 μs max.
Protection built into each point
Electronic overcurrent and short-circuit protection provides a dedicated protective function for each output.
REQUEST A QUOTE
IC670MDL730
Sales Manager
Miya Zheng

Email
sales@amikon.cn

Phone / WhatsApp
86-18020776792
CHECK PRICE & AVAILABILITY
Fast quotation request
Send the part number and required quantity for a precise quotation.

CORE PARAMETERS
Output performance at a glance
Eight-point positive-logic output architecture
01 / OUTPUT COUNT
8
Discrete output points
02 / LOAD CAPACITY
2 A
Maximum continuous load per point
03 / MODULE LIMIT
8 A
Maximum continuous module load
04 / RESPONSE
500 μs
Maximum on/off response time
Parameter IC670MDL730 Specification
User Input Voltage 18–30 VDC; 24 VDC nominal
Output Voltage Range 17.5–29.5 VDC
Outputs 8 discrete outputs
Continuous Load 2.0 A maximum per point; 8 A maximum per module
Inrush Current 10 A maximum per point for 10 ms
Overcurrent Trip Nominal range 2.25–2.75 A
Output Voltage Drop 0.5 V maximum
Output Leakage 0.5 mA maximum at 30 VDC
Short-Circuit Response 20 A for 100 μs
Protection Short-circuit protection, overcurrent protection and MOV
Bus Interface Unit Current 125 mA maximum
FIELD CONTROL ROLE
When an output point becomes critical


The IC670MDL730 provides a single group of eight discrete outputs for 24 VDC positive-logic control. The output electronics include protection against overcurrent and short-circuit conditions.

In a Field Control installation, an output fault can become significant when a commanded field device does not respond as expected. A failed output channel, persistent fault condition or loss of the required field supply can interrupt the operation of the connected device and may require maintenance attention before normal operation can continue.
FIELD CONDITION
Output point fault
A yellow fault indication can direct attention to an affected output point.
LOAD CONDITION
Overcurrent
The output protection is designed to respond to excessive current conditions.
CIRCUIT CONDITION
Short circuit
Each output incorporates electronic short-circuit protection.
SYSTEM IMPACT
Uncommanded device state
A failed output path can affect the field device controlled by that point.
QUOTATION REQUEST
Tell us exactly what you need

For a faster quotation, please include the following details in your inquiry:

Part Number IC670MDL730
Quantity Required quantity
Destination Shipping destination
Required Date Target delivery date
Machine / System Current installation
DIRECT CONTACT
Miya Zheng
Email sales@amikon.cn
Phone / WhatsApp 86-18020776792
Price inquiry
Contact us with the complete requirement and we will confirm the quotation and availability.
FREQUENTLY ASKED QUESTIONS
Questions engineers usually ask
01
What happens when one IC670MDL730 output exceeds its normal current level?
The output incorporates electronic overcurrent protection. The nominal steady-state overcurrent trip range is 2.25–2.75 A.
02
Is the 8 A rating intended for each output or for the complete module?
The module rating is 8 A maximum, while the continuous load limit is 2 A maximum for each output point.
03
What should be checked if an output shows a fault while the load is connected?
Check the connected load, field supply and wiring for conditions that could produce overcurrent or a short circuit, then verify the affected output indication.
04
Why can the output remain inactive even when the logic command is present?
The module requires the appropriate user field power. The output status indication also depends on the presence of user power.        .
05
What is the significance of the 500 μs response specification when replacing a module?
The specified maximum on and off response time is 500 μs. This is important when the replacement must maintain the expected timing behavior of the existing discrete output circuit.
