GE IC660BBD101 115 VAC · 8-Circuit Low-Leakage Discrete I/O Block

GE IC660BBD101
GE IC660BBD101
GE IC660BBD101

GE IC660BBD101 115 VAC · 8-Circuit Low-Leakage Discrete I/O Block

Calculate shipping
Quotation Request

GE · GENIUS I/O
IC660BBD101

115 VAC
8-Circuit
Low-Leakage I/O
Distributed control
built for practical
field I/O replacement.
KEY PARAMETERS
CIRCUITS
8 POINT

VOLTAGE
93–132 VAC

FILTER
10–100 ms
Intelligent discrete I/O for Genius bus architectures.
SALES CONTACT
Miya zheng

Reliable automation
parts support worldwide.
GE FANUC · GENIUS I/O Overview Specifications Application FAQ Contact
GENIUS DISTRIBUTED I/O
IC660BBD101
115 VAC · 8-Circuit Low-Leakage Discrete I/O Block

An intelligent configurable I/O block for discrete field devices, combining eight 115 VAC circuits with flexible input/output operation, circuit-level diagnostics and Genius communications.
PART NUMBER
IC660BBD101		   SIGNAL
115 VAC


GENIUS BLOCK
8 I/O

Configurable
Input / Output
PRODUCT PROFILE
Built for Flexible AC Discrete I/O
CIRCUIT ARCHITECTURE
8 Independent Circuits
Each circuit can be configured for input or output operation, allowing mixed I/O arrangements within the same block.

SIGNAL RANGE
93–132 VAC
Nominal 115 VAC operation with a 47–63 Hz frequency range.

OUTPUT CAPABILITY
2 A / Circuit
Designed for AC discrete loads with feedback and protective functions integrated into the block.
TECHNICAL DATA
IC660BBD101 Specifications
Parameter Specification
I/O configuration 8 circuits, individually configurable as input or output
Operating voltage 93–132 VAC, nominal 115 VAC
Frequency 47–63 Hz
Input processing Typical 2 ms + selected filter time
Input filter 10–100 ms selectable in 10 ms increments
Steady-state output 2 A RMS per circuit
Block output current 15 A at 35°C; 7.5 A at 60°C
Block-to-block isolation 1500 V
Standby power 8.5 W
Power dropout 1 cycle — 16.7 ms at 60 Hz / 20 ms at 50 Hz
Diagnostics Overtemperature, failed switch, open wire, overload and no-load detection
1500 V
ISOLATION
8
CONFIGURABLE CIRCUITS
2 A
PER CIRCUIT
10–100 ms
INPUT FILTER RANGE
FIELD APPLICATION
Where IC660BBD101 Matters
Distributed AC I/O
The block is suited to distributed control architectures where 115 VAC discrete sensors, switches and actuating devices need to exchange signals through a Genius communications network. Its configurable circuits allow a single block to accommodate mixed input and output requirements.

Maintenance-Critical Replacement
A failed field I/O block can prevent discrete signals from reaching the control system or leave connected loads without the required switching command. This makes the exact part number important when restoring an established Genius installation during a planned or unplanned shutdown.
DIAGNOSTIC VALUE
Output feedback allows the controller to verify the switched state after an appropriate delay. Electronic circuit protection can shut down an overloaded output, while diagnostics can report conditions such as overtemperature, failed switch, open wire, overload and no-load states.
RELATED MODELS
Related Automation Parts
IC660BBD023
IC660BBS101
IC660BBR101
IC660BBA105
IC660BBA106
PURCHASING QUESTIONS
IC660BBD101 FAQ
Why is the exact IC660BBD101 important when replacing a failed block?

Because this model combines 115 VAC operation with eight configurable circuits, its electrical role is tied closely to the existing field wiring and Genius I/O architecture. Matching the installed part number helps avoid an incompatible signal or load configuration.

Can the eight circuits be used for mixed input and output duties?

Yes. The circuits are individually configurable, allowing the block to operate as an inputs-only, outputs-only or combination block.
What should be checked when a field circuit repeatedly trips?

Review the connected load, wiring and circuit condition before replacing the block. The design includes electronic fusing and overload shutdown, so a recurring trip can indicate a field-side condition rather than an immediate need for another I/O block.

How can the block help when an output appears commanded but the field device does not respond?

Output feedback provides a way for the controller to monitor the actual switched condition. Combined with circuit diagnostics, this can help distinguish a block-side switching problem from a field-load problem.
Does the IC660BBD101 require a separate block power supply?

No separate block power supply is required. Control power is tapped from the input/output device voltages connected at the block terminals.
