IC660BBD024

32-Circuit Distributed Discrete Control

IC660BBD024 is designed for 12/24 VDC discrete I/O applications where a higher circuit count is required. It interfaces with binary field devices including 2-wire and 3-wire electronic proximity switches, while outputs can operate low-power control and indicating devices such as relays, contactors and lamps.

A failed block can affect a large group of field points because 32 circuits share the same block architecture. In a production line or process machine, that can manifest as missing sensor states, unavailable actuator commands or repeated sequence interlocks, increasing the risk of extended downtime while the affected I/O section is being restored.

Replacement Supply Arrangement

Quotation Request

Please provide Part Number, Quantity, Destination, Required Date and Machine/System for quotation.

It provides 32 discrete circuits and belongs to the 12/24 VDC Source I/O class, making it appropriate where the installed architecture requires this circuit density and voltage configuration.

The block interfaces with binary field devices, including 2-wire and 3-wire electronic proximity switches. Its outputs can operate low-power control and indicating devices such as relays, contactors and lamps.

When the block drives field loads directly, each circuit's steady-state current and inrush characteristics should be compared with the installed load. The specified steady-state output is 0.5 A per circuit.

A single block can serve many field points, so a block-level problem may affect a broader section of a machine. That is why exact replacement matching can be important during a production outage.

The output circuits include protective functions intended to limit the effect of abnormal load conditions, while diagnostic functions help indicate conditions such as short circuit, overload, no load, failed switch and overtemperature.
