| Manufacturer | GE / Emerson automation platform |
| Complete model | IC200CPUE05-MX |
| Family | VersaMax PLC |
| Hardware role | CPU with integrated Ethernet |
| The IC200CPUE05-MX is a VersaMax controller built around the IC200CPUE05 CPU platform. It combines controller execution, serial communication and an embedded Ethernet port in a compact modular station. The complete suffix must remain part of the purchasing code because installed revisions, firmware and regional configuration can affect replacement planning. The CPU executes the application, scans local and distributed I/O, maintains controller memory and exchanges plant signals over serial and Ethernet links. Ethernet Global Data supports scheduled controller-to-controller exchanges, while SRTP connections support programming and supervisory access. |
Selection rule Match function, complete catalog code, carrier or rack position, wiring, revision and controller compatibility. |
| Memory | 64 KB configurable application memory |
| Interfaces | RS-232, RS-485 and 10 Mbps Ethernet |
| Power draw | 5 V at 220 mA; 3.3 V at 570 mA |
| Ethernet services | SRTP server, EGD exchanges and NTP synchronization |
| Execution | 0.8 ms per K Boolean instructions, typical |
| Clock accuracy | 100 ppm; approximately 9 seconds per day |
| Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| IDENTITY | RELATIONSHIP | SELECTION POINT |
| IC200CPUE05-MX | Requested complete code | Match the installed marking and revision |
| IC200CPUE05 | Base CPU platform | Confirm suffix, firmware and approvals |
| IC200CPU005 | Non-Ethernet CPU family member | Not a network-equivalent replacement |
| IC200GBI001 | Network interface unit | Remote I/O role, not a CPU |
| 01 | Remove power before seating or removing the CPU and carriers. |
| 02 | Back up the application and record firmware, IP settings, EGD exchanges and serial-port parameters before replacement. |
| 03 | Confirm 5 V and 3.3 V power budgets for the assembled VersaMax station. |
| 04 | Restore the correct Ethernet address plan before reconnecting the plant network. |
|
20 YEARS OF INDUSTRIAL AUTOMATION SUPPLY
|
EXPEDITED DELIVERY COORDINATION
|
EXPERIENCED PART-MATCHING SUPPORT
|
|
01
|
Can IC200CPUE05-MX replace any IC200CPUE05?
Use the complete catalog marking. Confirm hardware revision, firmware, approvals, memory use and network configuration before substitution.
|
|
02
|
What should be backed up before replacing IC200CPUE05-MX?
Preserve the application, hardware configuration, Ethernet addressing, EGD exchanges, serial settings and retained values.
|
|
03
|
Does IC200CPUE05-MX support full-duplex Ethernet?
The embedded 10 Mbps port supports half- or full-duplex operation; the connected network equipment must use a compatible setting.
|
|
04
|
How many SRTP server connections can IC200CPUE05-MX accept?
The CPU platform supports up to eight simultaneous SRTP server connections.
|
|
05
|
What causes the most commissioning risk with IC200CPUE05-MX?
Address conflicts, mismatched firmware, omitted EGD exchanges and incorrect serial parameters are common replacement risks.
|
