| Manufacturer | GE / Emerson automation platform |
| Complete model | IC200ALG320F |
| Family | VersaMax I/O |
| Hardware role | 4-channel current output module |
| The IC200ALG320F is a VersaMax four-channel analog current output module based on the IC200ALG320 platform. It provides controlled 4–20 mA signals for positioners, converters, indicators and other process loads. The F suffix remains part of the complete replacement code and should be checked against the installed label and station configuration. Four controller output words are converted into independent current-loop signals. External field power supplies the loops, while the carrier connects the module to the VersaMax backplane. FLD PWR and OK indicators help separate field-supply conditions from module health. |
Selection rule Match function, complete catalog code, carrier or rack position, wiring, revision and controller compatibility. |
| Channels | 4 analog current outputs |
| Signal range | 4 to 20 mA |
| Resolution | 12-bit; 4 microampere per step |
| External power | 18 to 30 V DC, including ripple |
| Update time | 0.3 ms maximum |
| Accuracy at 25 C | ±0.3% full scale typical; ±0.5% maximum |
| Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| IDENTITY | RELATIONSHIP | SELECTION POINT |
| IC200ALG320F | Requested complete code | Four 4–20 mA outputs |
| IC200ALG320 | Base function | Check complete suffix and revision |
| IC200ALG326 | Eight-channel relative | Different channel count and conversion |
| Carrier base | Required station element | Match terminal style and wiring approach |
| 01 | Install the module on a compatible VersaMax carrier with station power removed. |
| 02 | Provide 18–30 V DC field power and verify polarity before energizing the loops. |
| 03 | Check the load and cable resistance so each loop remains within its available compliance voltage. |
| 04 | Record terminal assignments and commanded safe values before exchanging the module. |
|
20 YEARS OF INDUSTRIAL AUTOMATION SUPPLY
|
EXPEDITED DELIVERY COORDINATION
|
EXPERIENCED PART-MATCHING SUPPORT
|
|
01
|
Can IC200ALG320F be replaced by an eight-channel module?
Not as a direct exchange. Channel addressing, resolution, terminal arrangement, carrier use and project configuration differ.
|
|
02
|
Does IC200ALG320F power the field loops from the backplane?
No. The analog outputs require an external 18–30 V DC field supply.
|
|
03
|
What should be checked if IC200ALG320F shows no field power?
Verify the external supply, polarity, carrier terminals, protective devices and the field-power connection.
|
|
04
|
How quickly does IC200ALG320F refresh its outputs?
The module update time is 0.3 ms maximum.
|
|
05
|
What must be confirmed before ordering IC200ALG320F?
Confirm the full suffix, carrier type, revision, loop range, terminal arrangement and installed station compatibility.
|
