CATALOG NUMBER
IC670TBM002Auxiliary Terminal Block
A compact auxiliary connection point for Field Control I/O arrangements, with internally interconnected terminals for common, return and ground connections.
|
CONNECTION PROFILE
IC670TBM002
|
|
01 / TECHNICAL PROFILE
Connection Details |
Field Control auxiliary terminal arrangement
|
| A | Terminal quantity | 13 terminals |
| B | Terminal construction | Box-type terminals |
| C | Single-wire capacity | AWG #14 to AWG #22 |
| D | Two-wire capacity | Two wires up to AWG #18 |
| E | Electrical arrangement | All terminals internally interconnected |
|
01
Common Connections
Suitable for additional common connection arrangements.
|
02
Return Connections
Provides an auxiliary point for return wiring.
|
03
Ground Connections
Can provide additional ground connection points.
|
|
02 / FIELD USE
Built Around the Wiring PointIC670TBM002 is used with GE Field Control I/O arrangements as an auxiliary terminal block. Its internally interconnected terminals can provide additional common, return or ground connection points.
|
|
|
|
03 / RELATED MODELS
Other Automation Parts |
|
VV100-DUN01070
AZR31T0/24V B&R X20DO9322 OU5043 194L-E12-4503 XPSAM5140 140DDO35300 |
3RN1013-1BW10
MCR-C-UI-UI-DCI UE10-2FG3D0 INT69V 440R-D23171 MTN649330 1SVR650669R9400 |
BMXXBP0400
CS1W-ID211 3UF7100-1AA00-0 F3LR02-0N 1762-OW8/A 600-S 6ES5498-1AA41 |
AD866.13/05
PA419.134AX01 DVP08SM11N Q64AD 750 A436130 XN-PF-120/230VAC-D ESM-BA201 |
|
KSD2-FI-Ex
|
Looking for another industrial automation part? Send the exact part number for a quick quotation.
|
|
Q1
|
What makes IC670TBM002 different from IC670TBM001?
IC670TBM002 uses box-type terminals, while IC670TBM001 uses barrier-type terminals. The two auxiliary terminal blocks also differ in terminal quantity and wire accommodation.
|
|
Q2
|
Can the 13 terminals be used as separate electrical circuits?
No. The terminals are electrically connected together internally, so the block is intended for common, return, ground and other shared connection arrangements rather than isolated circuits.
|
|
Q3
|
What wire size should be considered when replacing this terminal block?
Each terminal accommodates one AWG #14 through AWG #22 wire. Two wires can also be accommodated when both are AWG #18 or smaller.
|
|
Q4
|
Why would an engineer search specifically for IC670TBM002 during maintenance?
The exact part number matters when the existing installation uses the box-terminal auxiliary arrangement. Matching the terminal style and electrical configuration helps avoid an unsuitable replacement.
|
|
Q5
|
What should be checked before ordering a replacement IC670TBM002?
Confirm the exact catalog number, box-terminal construction, 13-terminal arrangement, intended wiring function and required wire size before placing the replacement order.
|
|
