EPRO PR6423/010-100-CN CON021 Proximity Measurement Assembly

Since its establishment in Hong Kong in 2005, Amikon Technology has consistently positioned itself as a pioneer in the industrial automation sector.

Our core team, composed of seasoned engineers and industry experts, has built the company into a globally leading supplier of industrial automation components and control system solutions through twenty years of specialized dedication and relentless effort.

Through the team's collaborative spirit, Amikon has continuously expanded both its product portfolio and global market presence, now offering a comprehensive inventory including programmable logic controllers, human-machine interfaces, distributed control systems, and more.

This provides robust support for manufacturing clients worldwide. Guided by the principle of "technology-driven service," the team leverages precise supply chain management and professional technical support to help numerous enterprises extend equipment lifecycles and optimize production efficiency.

This commitment has made Amikon a trusted long-term strategic partner for manufacturers and system integrators globally.

Miya zheng

86-18020776792

sales@amikon.cn

Purpose-Built for Rotating Equipment

Designed specifically for machinery that depends on accurate shaft positioning and controlled rotor movement.

Supports Operational Analysis

Provides measurement data that can be used to evaluate machine behavior under different operating conditions.

Compact Mechanical Design

The probe can be installed in confined locations commonly found within industrial rotating equipment.

Stable Measurement Performance

Maintains consistent sensing characteristics during prolonged operation in demanding environments.

Non-Intrusive Measurement Method

Obtains displacement information without touching the monitored surface, eliminating mechanical interference.

Suitable for System Integration

Can be incorporated into monitoring platforms, machinery protection systems, and automation architectures.

Durable Industrial Construction

Built to withstand conditions commonly encountered in power generation, processing plants, and heavy industry.

Model Number

PR6423/010-100-CN CON021

Manufacturer

EPRO

Product Category

Eddy Current Measurement System

Probe Model

PR6423

Converter Model

CON021

Probe Diameter

8 mm

Measurement Principle

Eddy Current Technology

Measuring Range

2 mm

Sensitivity

8 V/mm

Initial Gap

0.5 mm

Frequency Response

Up to 20 kHz

Minimum Shaft Diameter

25 mm

Housing Material

Stainless Steel

Thread Type

M10 × 1

Protection Class

IP66

Converter Type

Signal Conditioner

Mounting Method

Fixed Installation

Application

Shaft Displacement Monitoring

Turbine Systems

Installed near bearing locations to provide displacement information for turbine shafts operating under changing load conditions.

Compressor Packages

Used in centrifugal and process compressors where shaft movement data contributes to machinery assessment.

Generator Units

Supports the observation of rotor position and movement characteristics during continuous operation.

Process Pumps

Suitable for pumps operating in chemical, petrochemical, and utility facilities where equipment availability is important.

Large Industrial Motors

Provides displacement measurement capability for motors used in critical production processes.

Fan and Blower Equipment

Applied to rotating assemblies where shaft stability and operating consistency are required.

What is the primary function of the PR6423/010-100-CN CON021?

The system is used to measure shaft displacement and related movement characteristics in rotating machinery.

Which equipment types commonly use this sensor?

It is frequently installed on turbines, compressors, generators, pumps, motors, and other critical rotating assets.

Does the sensor require contact with the shaft?

No. The measurement is performed through a non-contact eddy current sensing principle.

What is the purpose of the CON021 converter?

The CON021 processes signals generated by the probe and provides outputs suitable for monitoring and control systems.

Can this model be integrated into existing installations?

Yes. The sensor system can often be incorporated into both new equipment projects and retrofit monitoring upgrades.
