01
4 Channels
Four analog output channels
|
02
4–20 mA
Standard analog output range
|
03
HART
HART communication pass-through
|
04
-40 to +70°C
Specified ambient range
|
|
TECHNICAL PROFILE
Precise Output.
Compact CHARM. SE4304T01 is the DeltaV identification for the KL3022X1-BA1 analog output CHARM. It is intended for analog output applications using 4–20 mA signals and HART communication. CORE ROLE
Convert control demand into field-side analog output.
|
|
|
Signal Resolution
The 16-bit D/A converter provides fine digital-to-analog conversion for the four output channels. |
Field Power Capability
Field power is available at 20 mA and 15 VDC into a 750 Ω load under the specified conditions. |
Circuit Protection
The field circuit incorporates 24 mA current limiting and field wiring disconnect capability. |
|
FIELD APPLICATION
Where Analog Output
Meets the Process SE4304T01 / KL3022X1-BA1 is used in DeltaV control environments where controller commands must be delivered as analog field outputs. Typical duties include driving compatible valves, actuators and other continuously controlled field devices. |
|
|
01
Part Number
|
02
Quantity
|
03
Destination
|
04
Required Date
|
05
Machine / System
|
|
DELIVERY
3–5 Days
|
WARRANTY
12 Months
|
PACKAGING
Brand New
|
PAYMENT
T/T
|
|
QUESTION 01
Why is SE4304T01 the critical match when replacing a DeltaV 4–20 mA HART output?
SE4304T01 is the DeltaV model associated with KL3022X1-BA1 and is specifically defined as an analog output CHARM for 4–20 mA HART applications. Matching both designations helps avoid substituting an input or different output variant into the same position. |
QUESTION 02
Can SE4304T01 support smart field-device communication as well as analog control?
Yes. The KL3022X1-BA1 supports HART v7 pass-through while providing the analog 4–20 mA output function, making it suitable where a compatible smart field device needs both the control signal and HART communication path. |
|
QUESTION 03
What does the SE4304T01 four-channel architecture mean for a replacement order?
One CHARM provides four analog output channels. Before ordering, the maintenance team should verify that the installed position uses the same output function and signal type rather than selecting a visually similar DeltaV I/O variant. |
QUESTION 04
Why should SE4304T01 be checked carefully for temperature conditions?
The specified ambient range is -40°C to +70°C. Accuracy is specified as ±0.25% of span from 0–60°C and ±0.5% of span over the wider -40–70°C range, which matters when the CHARM is installed in demanding plant environments. |
|
QUESTION 05
When would a failed SE4304T01 create a genuine plant downtime concern?
If one or more output channels are part of an active control loop, losing the CHARM can interrupt the intended analog command to connected field equipment. The resulting maintenance window can become longer when an exact replacement is difficult to obtain, especially in an established DeltaV installation where matching the installed I/O function is important. |
|
|
SE4304T01
Control Output.
Keep Production Moving. For quotation, provide the exact part number, quantity, destination, required date and machine/system. |
