EMERSON PR9268/207-100 Electrodynamic Velocity Sensor

EMERSON PR9268/207-100
EMERSON PR9268/207-100
EMERSON PR9268/207-100

EMERSON PR9268/207-100 Electrodynamic Velocity Sensor

Calculate shipping
Quotation Request


EMERSON EPRO • PR9268 SERIES
PR9268/207-100

Electrodynamic velocity sensor configuration for vertical vibration measurement in rotating machinery monitoring systems.
◇  Vertical orientation
◇  Non-armored cable configuration
◇  PR9268 electrodynamic sensor family
CONFIGURATION HIGHLIGHTS
Measurement Vertical
Cable 10 m non-armored
Cable end Harting plug
Configuration code matters: cable construction and termination are integral to the specified PR9268 variant.
CONTACT AMIKON
Sales manager
Miya zheng
✉ sales@amikon.cn ☎ WhatsApp

AMIKON GLOBAL AUTOMATION SUPPLY   We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.



EMERSON AMS / EPRO

PR9268/207-100
Electrodynamic Velocity Sensor
CASE VIBRATION VERTICAL TYPE SELF-POWERED
MEASUREMENT CORE
Absolute Vibration
Designed for case-vibration measurement on critical rotating machinery such as turbines, compressors, pumps and fans.
PR9268/20x-x00 family
Vertical measurement orientation
Electrodynamic operating principle


01 / SENSITIVITY
28.5
mV/mm/s
Equivalent to 723.9 mV/in/s for the PR9268/20x and PR9268/30x dynamic-performance family.
◈
02 / FREQUENCY
4–1000
Hz
The specified operating frequency range covers low-frequency machinery vibration through higher-frequency components within the sensor's rated band.
◌
03 / NATURAL FREQUENCY
4.5
Hz ± 0.75 Hz @ 20°C
The low natural frequency supports the specified 4–1000 Hz measurement range of the PR9268/20x and PR9268/30x family.
◇
PRODUCT PROFILE
A sensor architecture built around machinery case vibration.


The Emerson EPRO PR9268 is an electrodynamic velocity sensor intended for absolute vibration measurement on critical turbomachinery. The product family is designed for applications including steam turbines, gas turbines, hydro turbines, compressors, pumps and fans, where vibration of the machine case or bearing housing is monitored.

The PR9268/207-100 belongs to the PR9268/20x vertical configuration. The 20x family uses a 28.5 mV/mm/s sensitivity and a 4 to 1000 Hz frequency range. The electrodynamic construction is self-powered, so the sensing element generates its measurement signal from the mechanical motion being measured rather than requiring a separate sensor excitation supply.

For replacement purchasing, the complete part identity matters. The 207 portion specifies a particular cable configuration within the PR9268 ordering structure, while the complete suffix should be retained when matching an existing installation. This is particularly important where cable length, cable construction and termination affect the mechanical installation and connection arrangement.
MEASUREMENT CHARACTER
Velocity measurement for rotating equipment monitoring
Absolute vibration
The sensor measures vibration velocity associated with machine case movement rather than shaft displacement through a proximity-probe arrangement.
Self-powered sensing
The PR9268 family is specified as self-powered, matching the electrodynamic sensing principle.
Critical machinery focus
Typical machinery includes steam, gas and hydro turbines, compressors, pumps and fans.
PERFORMANCE WINDOW
Sensitivity 28.5 mV/mm/s
Frequency Range 4–1000 Hz
Natural Frequency 4.5 Hz ± 0.75 Hz @ 20°C
Amplitude Linearity < 2%
Continuous Acceleration 10 g peak-peak
Intermittent Acceleration 20 g peak-peak
ENVIRONMENT & CONSTRUCTION
POWER
Self-Powered
The PR9268 family is specified as self-powered electrodynamic velocity sensing equipment.
TEMPERATURE
−20 to +100°C
The PR9268/20x and PR9268/30x configurations are specified for this operating temperature range.
PROTECTION
IP55
The 20x and 30x versions carry the IP55 protection classification in the current PR9268 specification.
CABLE
PTFE / 3 × 0.5 mm²
The PR9268 family uses PTFE cable with three 0.5 mm² conductors; cable armor depends on the ordered configuration.
PR9268/207-100
Variant-specific selection points

The PR9268 ordering structure combines measurement orientation, cable selection and cable-end selection. For a replacement, the complete part number should be matched rather than selecting only the common PR9268 family name.
Family position PR9268/20x — Vertical configuration
Cable code 7 — 10 m, non-armored cable
Cable-end code 1 — open cable end
Measurement orientation Vertical; PR9268/20x family
Primary measurement role Absolute vibration / machine case vibration
SAME SERIES / DIFFERENT CONFIGURATIONS
How PR9268 variants differ
The differences below are based on the PR9268 family configuration structure and specified performance groups.
FAMILY ORIENTATION FREQUENCY TEMPERATURE PROTECTION
PR9268/01x-x00 Omni Directional 14–1000 Hz −20 to +100°C IP65
PR9268/20x-x00 Vertical 4–1000 Hz −20 to +100°C IP55
PR9268/30x-x00 Horizontal 4–1000 Hz −20 to +100°C IP55
PR9268/60x-000 Vertical HT 10–1000 Hz −20 to +200°C IP65
PR9268/70x-000 Horizontal HT 10–1000 Hz −20 to +200°C IP65
Selection note
The PR9268/207-100 should not be substituted solely by matching the PR9268 family name. Orientation, cable length, cable construction and termination can all affect physical replacement compatibility. The high-temperature 60x/70x variants also have a different operating-temperature class and different dynamic-performance group.
ENGINEERING DETAIL
Dynamic performance of the 20x / 30x group
Transverse sensitivity 0.13 @ 110 Hz for 20x
Mechanical vibration limit 3000 µm peak-peak / 4000 µm peak-peak
Amplitude linearity < 2%
Maximum transverse acceleration 2 g
Damping factor ~0.56 @ 20°C; ~0.42 @ 100°C
Resistance 1875 Ω ± 10%
WHY THE 20x CONFIGURATION MATTERS
01 Vertical measurement geometry

The 20x family is the vertical version of the standard-temperature PR9268 configuration.

02 Standard-temperature architecture

Compared with 60x/70x high-temperature variants, the 20x/30x family is specified to −20 to +100°C rather than +200°C.

03 Long cable selection

The 207 configuration corresponds to the 10 m non-armored cable option in the PR9268 ordering structure, making the complete suffix relevant during replacement.
MATERIAL & CONNECTION
20x / 30x housing Al Mg Si Pb F 28
Cable PTFE, 3 × 0.5 mm²
Armor Stainless steel where the armored cable option is selected
Connector Harting plug / selected cable-end configuration
COMPLIANCE FRAMEWORK

The PR9268 family specification includes CE, ATEX, IECEx, CSA, UL and UKCA-related compliance entries. Exact hazardous-area applicability depends on the specific PR9268 configuration and approval combination rather than the family name alone.

For intrinsically safe applications, the exact model suffix and applicable approval designation should be matched before replacement or installation.


DIRECT PRODUCT SUPPORT
Need the exact PR9268/207-100 configuration?

Send the complete part number together with quantity, destination and required date. We can help confirm the requested configuration before order processing.
✉ EMAIL
sales@amikon.cn 		◉ PHONE / WHATSAPP
86-18020776792
Sales Manager: Miya zheng
For product selection, replacement matching and order coordination.
PURCHASING & APPLICATION FAQ
PR9268/207-100 — Five practical questions
Q1. Why does PR9268/207-100 need to be matched by its complete suffix?
Because the PR9268 ordering structure encodes the sensor orientation, cable selection and cable-end arrangement. The “207” portion corresponds to the vertical 20x configuration with the 10 m non-armored cable selection, while the complete part identity determines the physical connection arrangement. A replacement should therefore match the complete designation rather than only “PR9268”.
Q2. Is PR9268/207-100 intended for shaft displacement measurement?
No. The PR9268 is an electrodynamic velocity sensor for absolute vibration measurement, particularly machine case or bearing-housing vibration. Shaft displacement measurement is a different sensing function and should not be substituted simply because both technologies are used for rotating machinery monitoring.
Q3. Can PR9268/207-100 be replaced by a PR9268/307-100 without checking the installation?
The two configurations belong to different orientation groups: the 20x family is vertical and the 30x family is horizontal. Although both groups share the 28.5 mV/mm/s sensitivity and 4–1000 Hz frequency range, their mechanical orientation is different. Replacement therefore requires confirmation of the installed sensor orientation and mounting arrangement.
Q4. When should PR9268/207-100 be compared with the PR9268/60x family?
The 60x family is the vertical high-temperature configuration. It is specified for −20 to +200°C, whereas the standard 20x family is specified for −20 to +100°C. The 60x group also has a different dynamic-performance specification. If the installation operates above the 20x temperature range, the high-temperature family should be evaluated instead of treating the two as interchangeable.
Q5. What should a buyer confirm before ordering PR9268/207-100 as a replacement?
Confirm the complete part number, installed orientation, cable length, cable construction, cable-end arrangement, operating temperature and the measurement point on the machine. For hazardous-area installations, the applicable approval designation should also be checked. These details reduce the risk of receiving a sensor with the correct family name but a different mechanical or connection configuration.
