Emerson PR6424/011-110 16 mm eddy current sensor

Emerson PR6424/011-110
Emerson PR6424/011-110
Emerson PR6424/011-110

Emerson PR6424/011-110 16 mm eddy current sensor

Calculate shipping
Quotation Request
◉

E
D
D
Y

16MM
EMERSON EPRO · EDDY CURRENT SENSOR
PR6424/011-110

A 16 mm eddy-current sensor configuration for non-contact measurement of rotating-machine displacement and vibration.

SENSOR SIZE
16 mm
PR6424 sensor family
MECHANICAL FORM
M18 × 1.5
armored configuration
CABLE
5 m
LEMO connection configuration
∆
ROTATING EQUIPMENT MONITORING
Non-contact sensing supports shaft displacement, vibration and machine-condition monitoring applications.
AMIKON SUPPLY: We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.





EMERSON · EPRO
PR6424/011-110
16 mm Eddy Current Sensor

A non-contact eddy current sensor for continuous measurement of radial and axial shaft dynamic displacement, position, eccentricity and speed/key in critical rotating machinery.
SENSITIVITY
4 V/mm
101.6 mV/mil
STATIC RANGE
±2.0 mm
0.079 in
DYNAMIC RANGE
0–1,000 μm
0–0.039 in
◉ 16 MM ↕ NON-CONTACT ⌁ EDDY CURRENT ◇ TURBOMACHINERY


01 / ENGINEERING PROFILE
Designed for larger shaft geometry
The PR6424 uses a 16 mm sensing format and is intended for critical rotating machinery applications where larger shaft geometry and continuous non-contact displacement measurement are required.
PRIMARY MEASUREMENTS
Radial displacement · axial displacement · shaft position · eccentricity · speed/key
TARGET
Ferromagnetic steel · 42CrMo4 standard
Sensor format 16 mm
Sensitivity / linearity 4 V/mm · ≤ ±1.5%
Center air gap Approx. 2.7 mm
Long-term drift <0.3%
Maximum surface speed 2,500 m/s
Shaft diameter ≥80 mm
Operating temperature -35 to +150°C
Sensor-head pressure resistance 10,000 hPa / 145 psi
◌
CONFIGURATION FOCUS
PR6424/011-110 = M18×1.5 · armored cable · 50 mm sleeve · 5 m cable · LEMO end
The configuration code is important when replacing an installed probe because mechanical thread, sleeve length, cable construction and cable termination all affect installation compatibility.
02 / FAMILY COMPARISON
Choose the sensing format before the part number
PR6423
8 mm family
2 mm linear measurement range, 0.5 mm initial air gap and 8 V/mm ISF. Minimum shaft diameter is 25 mm.
Compact geometry
PR6424/011-110
16 mm family
4 V/mm sensitivity, ±2 mm static range, 0–1,000 μm dynamic range and ≥80 mm shaft diameter.
Large-shaft applications
MEASUREMENT CHAIN
Probe + converter
The probe forms part of an eddy-current measurement chain. Converter compatibility should be checked when replacing an installed sensor.
System matching
◈
SHAFT
Check diameter
⌁
TARGET
Check material
↕
GAP
Check installation
◎
CHAIN
Check converter

TEAM / SERVICE



AMIKON STOCK
Amikon's large stock is the core of our supply.
Our large stock of industrial products is ready for delivery. It contains more than 400,000 electronic products, such as PLC, HMI, drivers, servo and CNC devices, IPC and PG.
Whether new or out of production, from the smallest module to the complete configuration, we work to locate products required for maintenance and production.



GLOBAL INDUSTRIAL SUPPLY Market insight, technology development and customer demand enable us to buy strategically, so we seldom need to transfer business. If items happen to be out of stock, we will search our preferred supplier network for you.
We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.

DIRECT SALES SUPPORT
Ask about PR6424/011-110
Send the exact part number, quantity and application requirement to our sales team for availability and quotation.
✉ EMAIL
sales@amikon.cn		 ◉ PHONE / WHATSAPP
86-18020776792
SALES MANAGER
MIYA ZHENG
BUYER-FOCUSED QUESTIONS
PR6424/011-110 FAQ
01 · Is PR6424/011-110 interchangeable with every PR6424 configuration? No. The PR6424 family uses configuration codes for thread, armor, sleeve length, adapter, cable length and cable end. The complete code should match the installed arrangement.
02 · What makes PR6424/011-110 different from an 8 mm PR6423? PR6424 uses the 16 mm sensing format and is intended for larger shaft applications. PR6423 uses an 8 mm sensing format with a 2 mm linear measurement range.
03 · Why does the PR6424/011-110 configuration matter during retrofit? Its M18×1.5 thread, armored cable, 50 mm sleeve, 5 m cable and LEMO termination define how the probe physically and electrically fits the installed measurement chain.
04 · What shaft conditions are important for PR6424/011-110? The specified application uses ferromagnetic steel targets, 42CrMo4 as the standard target material, and a shaft diameter of at least 80 mm for the stated performance.
05 · What should be checked before ordering PR6424/011-110? Confirm the installed thread, sleeve dimension, armor requirement, cable length, connector type, target material, shaft diameter and compatible converter.
