EMERSON PR6424-00A-110 16 mm Eddy Current Sensor

Calculate shipping

Quotation Request

EMERSON / EPRO

PR6424-00A-110

16 mm Eddy Current
Sensor

Non-contact sensing for shaft displacement, vibration and position monitoring.

PR642x SENSOR FAMILY

CORE SPECIFICATIONS

01	SENSOR TYPE 16 mm Eddy Current Sensor
02	MEASUREMENT RANGE ±2.0 mm static / 0–1,000 μm dynamic
03	SENSITIVITY 4 V/mm ±1.5%

APPLICATION FOCUS

Critical rotating machinery such as turbines, compressors, pumps and fans.

PRECISION SENSING

Measure Motion.
Protect Assets.

We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.

CONTACT MIYA ZHENG

✉ EMAIL sales@amikon.cn ◉ PHONE / WHATSAPP CHECK AVAILABILITY →

Product Categories

Brands
- ABB
- BENTLY NEVADA
- HONEYWELL
- EMERSON
- ALLEN BRADLEY
- YOKOGAWA
- GENERAL ELECTRIC
- TRICONEX
- ICS TRIPLEX
- HIMA
- BACHMANN
- SIEMENS
- PROSOFT
- SCHNEIDER
- FOXBORO
- OTHERS

New Products

Product Details

PR6424 / 00A-110

PRODUCT SERIES CONTACT FAQ AMIKON RECOMMENDED

EPRO / EMERSON • EDDY CURRENT MONITORING

PR6424/00A-110

16 mm Eddy Current Sensor Platform

A non-contact eddy-current sensing platform for critical rotating machinery. The PR6424 family is intended for measurement of radial and axial shaft dynamic displacement, shaft position, eccentricity and speed/key functions when paired with the appropriate signal-conversion chain.

SENSITIVITY

4 V/mm

101.6 mV/mil

LINEARITY

≤ ±1.5%

dynamic performance

CENTER GAP

≈ 2.7 mm

nominal center position

APPLICATION FOCUS

Rotating Machinery Protection

Steam turbines • Gas turbines • Hydro turbines • Compressors • Pumps • Fans

Static range ±2.0 mm	Dynamic range 0–1,000 μm
Target Ferromagnetic steel	Shaft diameter ≥80 mm

MEASUREMENT ARCHITECTURE

Non-contact
shaft monitoring

The probe operates as part of a complete measurement chain. The sensing element works with compatible signal conversion to transform the eddy-current measurement into a usable displacement/vibration signal.

Sensing

Non-contact eddy-current measurement of conductive rotating targets.

Conversion

Compatible signal conversion provides the electrical measurement output.

Monitoring

Suitable for machinery displacement, position and dynamic monitoring.

ENGINEERING SNAPSHOT

PR6424 Performance Profile

DYNAMIC PERFORMANCE 4 V/mm sensitivity ≤ ±1.5% sensitivity / linearity specification	MEASUREMENT RANGE ±2.0 mm static 0–1,000 μm dynamic	MECHANICAL TARGET Ferromagnetic steel 42 Cr Mo4 standard target material	ENVIRONMENT −35 to 150 °C Operating temperature range
Maximum surface speed 2,500 m/s	Pressure resistance 10,000 hPa / 145 psi	Shock / vibration 5g @ 60 Hz @ 25 °C	Long-term drift < 0.3%

SERIES CONTEXT

PR6424 family

The PR6424 family is the 16 mm sensor platform within Emerson's PR642x eddy-current measurement range. Different PR6424 variants can use different configuration, cable and measurement-chain arrangements.

PR6423

8 mm-class eddy-current sensor family used where a smaller sensing diameter is appropriate.

Different physical sensor class from PR6424.

PR6424

16 mm eddy-current platform with a 4 V/mm sensitivity specification and a nominal center air gap of approximately 2.7 mm.

The PR6424/00A-110 belongs to this family.

PR6426

A separate PR642x sensor family used for larger measurement ranges and corresponding measurement-chain configurations.

Selection depends on the machinery geometry and required range.

Configuration note: PR6424 variants should not be treated as interchangeable solely because the base family number is the same. Probe configuration, cable arrangement, converter compatibility and the required measurement range should be checked against the installed measurement chain before replacement.

EPRO

PURCHASING SUPPORT

Need PR6424/00A-110?

Send the exact part number, required quantity, destination and required delivery date for a focused quotation.

SALES MANAGER Miya zheng	EMAIL sales@amikon.cn
PHONE / WHATSAPP 86-18020776792

BUYER QUESTIONS

PR6424/00A-110 FAQ

Can PR6424/00A-110 replace another PR6424 variant directly? Not automatically. PR6424 variants can differ in probe configuration, cable arrangement and measurement-chain requirements. The installed converter and complete probe-chain configuration should be checked before a replacement is selected.	What machinery measurements can PR6424/00A-110 support? The PR6424 platform is intended for non-contact measurement of radial and axial shaft dynamic displacement, shaft position, eccentricity and speed/key applications in critical rotating machinery.
What should be checked before ordering PR6424/00A-110 for an existing system? Check the complete installed chain: probe variant, cable arrangement, converter compatibility, target material, required measurement range and the mechanical installation geometry. These factors determine whether a particular PR6424 configuration is suitable.	Why does the PR6424/00A-110 configuration matter for machinery replacement work? Eddy-current systems operate as a matched measurement chain. A probe with the same family number may still have a different configuration. Matching the installed arrangement helps avoid mechanical or electrical mismatch during maintenance.
What performance characteristics make PR6424/00A-110 suitable for demanding rotating equipment? The PR6424 family provides 4 V/mm sensitivity, ≤ ±1.5% sensitivity/linearity, approximately 2.7 mm nominal center air gap, ±2.0 mm static range, 0–1,000 μm dynamic range and a long-term drift specification below 0.3%. These characteristics support precision shaft-displacement monitoring in appropriate measurement-chain installations.
