EMERSON DELTAV / S-SERIES
KJ3222X1-BA3
8-Channel Analog Input · 4–20 mA HART · Series 2
|
HART / AI |
|
◎ CHANNELS
8 Channels
Analog input
|
⌁ SIGNAL
4–20 mA
HART communication
|
ϟ LOCAL BUS
12 VDC
150 mA
|
| International Delivery on the Day Quick Response Support Intercontinental Cooperation Network |
✉ Email Sales ☏ WhatsApp |  |
| Emerson KJ3222X1-BA3 is a DeltaV S-series Series 2 analog input card for eight 4-20 mA HART loops. It receives analog process signals while supporting HART communication through the installed DeltaV I/O assembly. The keyed carrier and terminal-block arrangement must match this card before insertion. |
INSTALLED FAMILY
DeltaV S-series I/O
8 AI / 4-20 mA / HART / SERIES 2
|
| PRICE & AVAILABILITY | Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| Product type | AI 8-channel 4-20 mA HART card, Series 2 |
| Local bus power | 12 VDC at 150 mA |
| Bussed field power | 24 VDC at 300 mA |
| Field circuit | 24 VDC at 30 mA per channel |
| Terminal-block key position | A1 |
| Ambient temperature | -40 to +70 deg C |
| Relative humidity | 5 to 95%, non-condensing |
| Shock | 10 g half-sine for 11 ms |
| Vibration | 1 mm p-p from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz |
| Airborne contaminants | ISA-S71.04 Class G3 |
|
SYSTEM POSITION
8 AI / 4-20 mA / HART / SERIES 2
|
The card is the analog acquisition stage between eight powered field loops and the DeltaV controller environment. It digitizes the 4-20 mA process values and provides the hardware path for HART communication. Field power, terminal-block keying and the energy-limited loop assessment are part of the installed configuration. |
| MODEL / FAMILY | RATING OR ROLE | SELECTION POINT |
| KJ3222X1-BA3 | 8-channel 4-20 mA HART, Series 2 | This model and execution |
| KJ3222X1-BA1 | Earlier 8-channel HART variant | Check revision and installed carrier |
| KJ3221X1-BA1 | Analog input family variant | Different electrical execution |
| KJ3224X1-EA1 | Discrete-input family | Different signal type |
| KJ3201X1-BA2 | Discrete-output family | Output role; not interchangeable |
| 01 | Confirm the complete BA3 code, Series 2 execution and A1 terminal-block keying. |
| 02 | Remove field power and system power before removing or connecting the card. |
| 03 | Complete the required assessment for all energy-limited I/O nodes. |
| 04 | Record channel assignments, HART devices, loop power arrangement and terminal positions. |
| 05 | After installation, verify analog values, loop current, HART communication and card diagnostics on all eight channels. |
|
