Emerson KJ1501X1-BK2 24 VDC System Power Supply Module

Calculate shipping

Quotation Request

EMERSON

DELTAV S-SERIES

KJ1501X1

— BK2

S-SERIES SYSTEM
POWER SUPPLY

POWER MODULE / 001

HARDWARE PROFILE

SYSTEM POWER ARCHITECTURE

VDC INPUT

±20%

VDC OUTPUT

8 A / 6 A

5.1 / 3.4

AUX. RAILS

2 A EACH

Designed for DeltaV S-Series system power architecture with multiple regulated DC rails.

TEMPERATURE

-40°C → +70°C

CATEGORY

SYSTEM POWER

AMIKON DIRECT

TALK TO US

SALES MANAGER

Miya zheng

›

sales@amikon.cn

›

86-18020776792

›

AMIKON

We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.

INDUSTRIAL

AUTOMATION PARTS

Product Categories

Brands
- ABB
- BENTLY NEVADA
- HONEYWELL
- EMERSON
- ALLEN BRADLEY
- YOKOGAWA
- GENERAL ELECTRIC
- TRICONEX
- ICS TRIPLEX
- HIMA
- BACHMANN
- SIEMENS
- PROSOFT
- SCHNEIDER
- FOXBORO
- OTHERS

New Products

Product Details

EMERSON / DELTAV™ / S-SERIES

KJ1501X1-BK2

24 VDC System Power Supply

The Emerson KJ1501X1-BK2 is a DeltaV S-series system power supply designed to accept a 24 VDC bulk-power input and provide regulated system rails for DeltaV control hardware. Its 12 VDC output supports the LocalBus/I/O power architecture, while dedicated 5.1 VDC and 3.4 VDC rails support controller electronics when the supply is used in the appropriate Power/Controller Carrier arrangement.

S-SERIES 24 VDC INPUT 12 VDC SYSTEM POWER

SYSTEM POWER

24 VDC

12 VDC / 5.1 VDC / 3.4 VDC rails

INPUT

24 VDC ±20%

6.1 A maximum rated input current

MAIN OUTPUT

12 VDC

8 A at -40 to +60°C; 6 A at 60 to +70°C

AUXILIARY RAILS

5.1 / 3.4 VDC

2 A per rail; 10.2 W combined

AMBIENT

-40 to +70°C

Industrial operating temperature range

POWER ARCHITECTURE

Input & Conversion

KJ1501X1-BK2 is configured for a 24 VDC bulk-power environment. The rated input range is 24 VDC ±20%, with an input current rating of 6.1 A. The supply converts the incoming DC power into regulated system rails required by the DeltaV S-series architecture.

Parameter	Value
Input voltage	24 VDC ±20%
Input current	6.1 A
Primary role	System power conversion

Output Rail Structure

The principal 12 VDC system output is complemented by 5.1 VDC and 3.4 VDC auxiliary rails. The auxiliary outputs are each rated at 2 A, with a combined 10.2 W limit for the 5.1 VDC and 3.4 VDC outputs.

12 VDC OUTPUT CAPABILITY

8 A from -40 to +60°C

6 A from +60 to +70°C

AUXILIARY POWER

5.1 VDC / 2 A

3.4 VDC / 2 A

10.2 W combined maximum

Designed Around the DeltaV S-Series Power Path

In an S-series DeltaV installation, the system power supply sits within the power/controller carrier architecture and establishes the electrical foundation for controllers and I/O interfaces. The KJ1501X1-BK2 is specifically associated with the S-series implementation and a 24 VDC system-power arrangement.

The regulated 12 VDC rail is the principal system-power path. The temperature-dependent current rating should be considered when assessing cabinet loading, especially when ambient conditions approach the upper operating limit.

-40 to +60°C	12 VDC / 8 A
+60 to +70°C	12 VDC / 6 A
Auxiliary rails	5.1 V / 3.4 V

SYSTEM RELATIONSHIP

Where KJ1501X1-BK2 Fits

TARGET FAMILY

KJ1501X1-BK2

DeltaV S-series 24 VDC system power supply. It accepts a 24 VDC bulk-power input and provides the regulated rails used within the S-series power architecture.

RELATED M-SERIES FAMILY

KJ1501X1-BC5

The BC5 designation belongs to the M-series version of the same broad system-power family. It should not be treated as an interchangeable substitute simply because the electrical family is related.

SYSTEM FUNCTION

Power + Control Hardware

The system power supply works with the carrier and DeltaV controller/I/O architecture. Correct series and carrier compatibility matter when replacing an installed module.

Replacement Checkpoint

When replacing KJ1501X1-BK2, verify the DeltaV S-series architecture, carrier arrangement, 24 VDC bulk-power configuration, and required output loading rather than selecting a power supply by voltage alone.

AMIKON GLOBAL INDUSTRIAL SUPPLY

Sustainable Supply.
Efficient Industry.

At AMIKON, our mission is to promote a sustainable and efficient global industrial supply chain. As a global distributor with more than 1 million hard-to-find industrial parts in inventory, we help system integrators and suppliers reduce unexpected shortages and extended lead times.

Long-term industrial asset partnerships across multiple industries enable us to support sourcing for new and discontinued industrial parts, equipment and machinery.

1M+ INDUSTRIAL PARTS	FAST DELIVERY
ATTENTIVE SERVICE	SUPPLY CHAIN SUPPORT

REQUEST A QUOTE

Need KJ1501X1-BK2 for an Existing DeltaV System?

Send the part number, required quantity, destination, required date and machine/system details. For replacement projects, including the existing system or carrier information can help us check the appropriate configuration more efficiently.

Delivery: 3–5 Days Warranty: 12 Months Brand New Packaging

AMIKON LIMITED

Sales Manager: Miya Zheng

Email: sales@amikon.cn

Phone / WhatsApp: +86 180 2077 6792

EMAIL SALES WHATSAPP

Delivery
E-packing / FedEx / EMS / TNT / DHL / UPS

Payment
T/T

Warranty
12 Months

Packaging
Brand New

Lead Time
3–5 Days

After-Delivery Support

Clear handling for return or replacement requests.

01 / CONTACT

Please contact us within 7 days after receiving the items if an issue occurs.

02 / CONDITION

Returned items should remain in their original condition and include the specific reason for the return.

03 / SHIPPING

Return or replacement processing starts after the returned item is received. Return shipping costs are the buyer's responsibility.

PURCHASING QUESTIONS

KJ1501X1-BK2 FAQ

Can KJ1501X1-BK2 replace a different DeltaV system power supply simply because both use 24 VDC input?

Not necessarily. KJ1501X1-BK2 is associated with the DeltaV S-series 24 VDC system-power architecture. Replacement should be checked against the installed DeltaV series, carrier arrangement, required output rails and load rather than input voltage alone.

What should be checked before ordering KJ1501X1-BK2 for a cabinet operating above 60°C?

The temperature-dependent 12 VDC rating is important. KJ1501X1-BK2 is rated for up to 8 A at -40 to +60°C, while the 12 VDC output rating decreases to 6 A from +60 to +70°C. The actual cabinet load should therefore be evaluated against the applicable ambient range.

Why does KJ1501X1-BK2 have 5.1 VDC and 3.4 VDC outputs in addition to its 12 VDC rail?

The supply is designed around the DeltaV system-power architecture rather than functioning as a general-purpose 24-to-12 VDC converter. The 5.1 VDC and 3.4 VDC rails support the associated control electronics, with each auxiliary rail rated at 2 A and a combined 10.2 W limit.

If an existing cabinet uses KJ1501X1-BC5, is KJ1501X1-BK2 the correct direct replacement?

The two part numbers belong to related DeltaV system-power families, but KJ1501X1-BC5 is associated with the M-series while KJ1501X1-BK2 is associated with the S-series. The installed system series and carrier configuration should be confirmed before treating either model as a replacement for the other.

What electrical details should be included when requesting a quotation for KJ1501X1-BK2?

For a replacement or project quotation, provide the exact KJ1501X1-BK2 part number, quantity, destination, required date and the installed DeltaV system or carrier information. If the cabinet operates near the upper temperature range, include the expected ambient condition so the 12 VDC load requirement can be checked against the applicable rating.
