CHANNELS
16
Independent analog output channels
|
OUTPUT
4–20 mA
Analog output with HART Plus capability
|
FIELD CIRCUIT
17 VDC
23 mA specified field-circuit value
|
AMBIENT
−40 to +70°C
Specified operating temperature range
|
|
Sixteen Analog Outputs
KC3011X1-BK1 provides sixteen independent analog output channels. The output signal is specified as 4–20 mA DC, making the card suitable for process-control loops where an analog current command is required by the field device.
SIGNAL ARCHITECTURE
16 × independent 4–20 mA outputs
The high channel density allows multiple analog control loops to be handled through one S-series I/O card position, helping consolidate cabinet I/O while maintaining individual output channels.
|
HART Plus Capability
The HART Plus architecture combines the analog 4–20 mA process signal with HART communication capability. This allows compatible smart field devices to participate in digital communication while the analog current loop continues to perform its process-control function.
COMMUNICATION
HART communication supported
This combination is particularly relevant where analog control and smart-device communication are both required within the same process loop architecture.
|
|
TEMPERATURE
−40 to +70°C
Ambient operating range
|
HUMIDITY
5–95%
Relative humidity, non-condensing
|
AIRBORNE CONTAMINANTS
ISA-S71.04
Class G3 environmental condition
|
|
KC3011X1-BK1
AO 16-Ch HART Plus
Sixteen 4–20 mA analog output channels with HART Plus capability. It is intended for analog control output applications involving compatible smart field devices.
|
KC3010X1-BK1
AI 16-Ch HART Plus
The related S-series KC3010X1-BK1 is an analog input card, while KC3011X1-BK1 is the corresponding analog output family position. The direction of the process signal is therefore a key selection difference.
|
KC3021X1-BK1
DI 32-Ch Plus
KC3021X1-BK1 belongs to the S-series digital-input family. It is not an analog-output replacement: its signal type and channel architecture are fundamentally different from KC3011X1-BK1.
|
|
Terminal Compatibility
The S-series I/O architecture uses a rotary keying system to maintain compatibility between an I/O card and its associated terminal block. For KC3011X1-BK1, the specified terminal-block key position is A5.
KEY POSITION
A5
|
Removal & Insertion
KC3011X1-BK1 must not be inserted or removed while system power is energized. Field power supplied to the device, whether supplied at the field terminal or through the carrier as bussed field power, must be removed before connecting or disconnecting the device.
SERVICE CONDITION
Remove applicable field power before device connection or removal.
|
|
1M+ INDUSTRIAL PARTS
|
FAST DELIVERY
|
|
ATTENTIVE SERVICE
|
SUPPLY CHAIN SUPPORT
|
|
REQUEST A QUOTE
Looking for KC3011X1-BK1?
Send the exact part number, required quantity, destination, required date and machine/system details. For replacement projects, including the installed DeltaV series and I/O arrangement can help us handle the request more efficiently.
Delivery: 3–5 Days Warranty: 12 Months Brand New Packaging
|
