M-SERIES SYSTEM POWER

EMERSON KJ1501X1-BC5

DeltaV System DC Power Supply

Power Conversion for DeltaV M-Series Assemblies

KJ1501X1-BC5 is an M-series system DC power-supply module. It converts the incoming DC supply into regulated system rails used by the associated DeltaV control hardware. The complete power assembly, carrier position, input range and output loading must be matched before replacement.

The documented input is 24 VDC ±20%, with a maximum current value of 6.1 A for the power-supply family. The unit supports multiple regulated outputs for the system assembly and is rated for industrial ambient temperatures from -40°C to +70°C.
24VDC
M-Series system supply
Industrial cabinet installation
IP20 module enclosure
Input
24 VDC ±20%		 Ambient
-40°C to +70°C		 Protection
Install in the specified enclosure
POWER-SUPPLY ENGINEERING DETAIL

Input Conversion, Regulated Rails and Cabinet Integration

The KJ1501X1-BC5 forms part of the DeltaV M-series system-power architecture. It accepts the plant 24 VDC feed and supplies regulated low-voltage rails to the associated control assembly. Correct selection depends on the complete suffix code, input tolerance, output loading, carrier connection and enclosure conditions.

Area Electrical characteristic Practical check
DC input stage 24 VDC ±20%; family maximum 6.1 A Confirm supply voltage, protective device, conductor capacity and polarity.
Primary regulated rail 12 VDC output; available current depends on temperature and assembly loading Evaluate the full installed load instead of choosing by connector shape alone.
Auxiliary rails 5.1 VDC and 3.4 VDC outputs within the specified combined-load limit Keep total rail demand within the approved system-power budget.
Operating environment -40°C to +70°C; IP20 module construction Use the required industrial enclosure and maintain cabinet ventilation.
Temperature and loading
Available output capacity is affected by ambient temperature and installed assembly. Review cabinet heat, neighboring equipment and expected system demand together.		 Replacement matching
Match the full KJ1501X1-BC5 designation, mating arrangement and regulated-rail requirements. A physically similar supply is not automatically electrically interchangeable.		 Protection boundary
IP20 does not provide a complete field enclosure. The installed cabinet must deliver the environmental and access protection required by the site.

Installation and Startup Check

Before removal
De-energize the incoming DC feed and verify absence of voltage.		 Before installation
Check model code, polarity, carrier connection and enclosure condition.		 At startup
Confirm regulated outputs, status behavior and stable system operation.		 Under load
Watch cabinet temperature and verify that the assembly remains within its power budget.
Replacing an M-series system supply?
Send the complete code, input supply, installed carrier and system arrangement.		 REQUEST QUOTE

System Power Relationship

24 VDC Input
Plant DC supply		 → KJ1501X1-BC5
DC/DC conversion		 → DeltaV System Rails
Associated M-series hardware
Replacement advantage: using the same complete model preserves the intended supply architecture. A visually similar power module is not automatically equivalent; verify input tolerance, regulated outputs, current capability, temperature limits and carrier connection.
Amikon's large stock is the core of our supply. 400,000+ products
From current technology to long-unavailable parts.		  Ready for international delivery
Multilingual support · order tracking · transparent handling

Contact Miya Zheng for KJ1501X1-BC5

EMAIL sales@amikon.cnWHATSAPP 86-18020776792
Return support: Contact us within 7 days after receipt. Keep original condition and state the reason. Review begins after the return arrives; return shipping is the buyer's responsibility.

KJ1501X1-BC5 FAQ

Is KJ1501X1-BC5 an I/O card?
No. It is a system DC power-supply module for the DeltaV M-series power architecture.
Can KJ1501X1-BC5 replace any DeltaV power supply?
No. Match the complete model, input range, regulated outputs, carrier connection and required current capacity.
What input should be checked for KJ1501X1-BC5?
Confirm a 24 VDC supply within the permitted ±20% range and verify the installation's current and protection arrangement.
Can KJ1501X1-BC5 be opened for field repair?
No. It is not intended for component-level user servicing. Do not disassemble it.
What should a buyer send for KJ1501X1-BC5 matching?
Send the full label code, installed supply arrangement, carrier type, ambient requirement and quantity.
