AMS EZ 1000 / EDDY CURRENT SENSING
Emerson EZ1080-10-00-0108 mm Eddy Current Proximity Sensor • M10 × 1 • 100 mm Case • 1 m Cable
|
|
A Compact Sensor for Precision Shaft Measurement
The Emerson AMS EZ1080 sensor is an 8 mm eddy current proximity sensor designed for non-contact measurement of conductive targets. Within the AMS EZ 1000 measurement chain, the EZ1080 family can be used for shaft displacement, radial vibration, position, eccentricity and speed-related measurements. The EZ1080-10-00-010 configuration combines an 8 mm sensor tip with an M10 × 1 sensor body, a 100 mm case length, no additional unthreaded length and a 1.0 m sensor cable. The standard EZ1080 configuration is non-armored. The sensor works as part of a calibrated eddy-current measurement chain. The sensing principle permits measurement without mechanical contact between the sensor and the conductive machine target, making the technology suitable for rotating machinery monitoring. CONFIGURATION SNAPSHOT
EZ1080-10-00-010
8 mm sensing diameter · M10 × 1 body · 100 mm case · 0 mm unthreaded section · 1 m cable · non-armored configuration
|
MODEL ARCHITECTURE
EZ1080 / 10 / 00 / 010
PRIMARY ROLE
Non-contact displacement sensing
The sensor is intended to operate with the AMS EZ 1000 Converter as part of a calibrated eddy-current chain.
|
|
TECHNICAL PROFILE
EZ1080-10-00-010 at a Glance
|
|
|
|
|
|
Installation Conditions That Matter
|
|
SERIES / SYSTEM RELATIONSHIP
Where EZ1080-10-00-010 Fits
The EZ1080 belongs to the AMS EZ 1000 sensor family. The family uses different sensor diameters and mechanical configurations to address different measurement ranges and installation constraints. |
|||
|
|||
|
Sensor + Converter = Calibrated Measurement Chain
The EZ1080 is not intended to be treated as an isolated generic proximity switch. It operates within an eddy-current measurement chain with the AMS EZ 1000 Converter. The converter is configurable for EZ108x sensors and supports a standard 2.0 mm range or extended 3.0 mm and 4.0 mm range configurations. The converter provides the electrical interface and output processing for the measurement chain. |
|
PURCHASE SUPPORT
Request EZ1080-10-00-010
For a quotation, please provide the exact model, quantity, destination, required delivery date and machine/system application when available. This helps us confirm the correct configuration before order processing.
|
AMIKON LIMITED
Talk to Sales
sales@amikon.cn WhatsApp: +86 18020776792
Sales Manager: Miya Zheng
Part Number • Quantity • Destination Required Date • Machine/System |
|
Return / Replacement Terms
|
|
BUYER-FOCUSED FAQ
Before Ordering EZ1080-10-00-010
|
|
Can EZ1080-10-00-010 be used when the existing installation requires an 8 mm sensing tip but has limited thread space?
The EZ1080 family uses an M10 × 1 case thread, and this specific configuration has a 100 mm case with 0 mm unthreaded length. The mechanical envelope should therefore be checked against the available installation depth and holder arrangement before purchase. The sensor should also maintain the specified free space around the sensing region. Is EZ1080-10-00-010 suitable for a standard 2 mm shaft-displacement measurement chain?
Yes, the EZ108x family has a standard 2.0 mm measurement range when configured with the AMS EZ 1000 Converter at the standard range factor. The converter can also be configured for extended 3.0 mm and 4.0 mm ranges where the application permits and the complete chain is calibrated accordingly. What should I verify if EZ1080-10-00-010 is replacing another 8 mm proximity probe?
Do not compare only the tip diameter. Verify the M10 × 1 mechanical thread, 100 mm case length, 0 mm unthreaded length, cable arrangement, target material, shaft diameter, required measuring range and the compatible converter configuration. A replacement should be treated as a complete measurement-chain compatibility check. What target and shaft dimensions should be checked before ordering EZ1080-10-00-010?
For EZ108x sensors, the technical conditions specify a minimum shaft diameter of 20 mm and recommend more than 25 mm. The minimum target size is 14 mm, while 20 mm or larger is recommended. These dimensions affect the available sensing area and the resulting measurement behavior. Does the 1 m cable on EZ1080-10-00-010 determine the final system cable length?
The model contains a 1.0 m sensor cable. If an extension cable is used, the total sensor-plus-extension system length must remain within the permitted system configurations. Emerson specifies compatible EZ190x extension options for the AMS EZ 1000 sensor system, so the required final cable length should be confirmed when the order is prepared. |
|
