EMERSON A3311-022-000 Machinery Speed, Key, and Phase Transmitter

EMERSON A3311-022-000
EMERSON A3311-022-000
EMERSON A3311-022-000

EMERSON A3311-022-000 Machinery Speed, Key, and Phase Transmitter

Calculate shipping
Quotation Request

EMERSON • AMS MACHINERY HEALTH • TRANSMITTERS ◆◆◆


A3311-022-000 AMS Machinery Health Transmitter
Architecture: Dual-Channel Transmitter
Signal Outputs: 4-20 mA Current Loop
Communication: RS485 Modbus RTU
■ GLOBAL SERVICES
We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.

SALES MANAGER Miya zheng Email: sales@amikon.cn   WhatsApp: 86-18020776792


EMERSON / CSI MACHINERY HEALTH
A3311-022-000
Speed & Key Monitor
A compact monitoring unit designed for small and low-channel rotating machinery applications where reliable shaft-speed measurement and key-signal generation are required. The A3311-022-000 configuration uses an internal eddy-current converter and provides configurable measurement, alarm and output functions.
KEY CONFIGURATION
Internal Converter

Input: Eddy-current sensors
Frequency: 0–20 kHz
Speed: Up to 65,535 rpm
Protection: IP65
01 / PRODUCT DETAIL
Precision Speed & Key Monitoring

Industrial rotating equipment

Product Overview
The Emerson CSI 3311 family is intended for small and low-channel machinery monitoring applications. The A3311-022-000 is the internal-converter configuration for speed and key monitoring. It is designed to measure rotational speed and generate key signals on equipment such as small steam, gas and hydro turbines, compressors, pumps and fans. Measurement settings, alarm functions and available outputs can be configured for the installation.
The unit accepts eddy-current sensor signals and supports a configurable measurement range up to 65,535 rpm, subject to the input-frequency limit. An automatic trigger-level function supports reliable signal detection, while isolated current outputs, buffered voltage outputs and relay contacts provide practical interfaces for control, monitoring and protection circuits.

Functional Highlights
Sensor Interface Eddy-current sensors
Speed Range Selectable; max. 65,535 rpm
Frequency 0–20 kHz
Trigger Level Automatic setting
Connection Internal converter / LEMO socket
Mounting Wall mount
Why This Configuration Matters
The A3311-022-000 integrates the eddy-current conversion function inside the monitoring unit. This distinguishes it from configurations intended for an external converter and can simplify the arrangement when the installation is designed around the internal-converter architecture.
For rotating equipment where speed and a repeatable key signal are important to the control or condition-monitoring chain, the unit provides multiple output paths for integration with monitoring and control equipment.
Its wall-mounted construction, IP65 sealing and -20 to +65 °C operating range make it suitable for industrial machinery monitoring installations within the specified environmental limits.

TECHNICAL DATA
A3311-022-000 Specifications
Parameter Specification Application / Interface
Input type Eddy-current sensors Rotational-speed and key-signal measurement
Measurement range Selectable; maximum 65,535 rpm Limited by the input frequency
Frequency range 0–20 kHz Sensor signal processing
Linearity error 0.25% at 25 °C Basic monitor performance
Linearity with sensor Depending on sensor, max. -6% at 25 °C Overall measurement chain consideration
Temperature stability <0.08% / 10 K Output stability versus temperature
Long-term drift Max. 1% of measuring range Long-term measurement stability
Buffered output 2 × 2.0–10.0 VDC; ±2.5% accuracy Buffered signal connection via pins / cage terminal
Current output 2 × 0/4–20 mA Galvanically separated; open- and short-circuit protected
Current-output burden Maximum 500 Ω Analog signal-loop design
Relay output 5 × make contact Alarm / control interface
Relay rating 48 VDC max.; 1 A max.; 50 W max. Contact-load limits
Power supply Nominal +24 VDC; +18 to +31.2 VDC DC industrial power system
Power consumption Maximum 6 W Allow for maximum consumption during panel design
Operating temperature -20 to +65 °C -4 to +149 °F
Shock limit 20 g peak Industrial mechanical environment
Ingress protection IP65 Enclosed industrial installation
Agency rating CE Applicable installation requirements should be checked
Construction Aluminum / stainless; approx. 1300 g Wall-mounted industrial enclosure

RELATED CSI MONITORING FAMILY
Same-Series Selection
The CSI 31xx monitoring family covers several measurement functions for rotating machinery. Selecting a related model should be based on the measured physical quantity, sensor technology and required output arrangement rather than by model number alone.
Model Function Typical Selection Logic
A3110 Shaft vibration Used when relative shaft-vibration measurement is the primary requirement.
A3120 Bearing vibration For absolute bearing-vibration measurement using compatible seismic sensors.
A3125 Bearing vibration For ICP piezo-electric sensor based bearing-vibration measurement.
A3210 Shaft position For relative shaft-displacement / position monitoring.
A3311-022-000 Speed & key For rotational-speed measurement and key-signal generation with internal eddy-current conversion.
Where It Fits
The A3311-022-000 is suited to machinery where rotational speed is a critical operating variable or where a repeatable key signal is required for monitoring and analysis.
Typical equipment includes small steam turbines, gas turbines, hydro turbines, compressors, pumps and fans. The output structure allows the measured signal and alarm functions to be incorporated into a wider machinery-monitoring or control architecture.
It is particularly relevant when an existing installation requires the internal-converter configuration and the replacement must match the established sensor and signal arrangement.
Replacement Checkpoints
• Confirm the exact A3311-022-000 configuration.
• Verify the existing eddy-current sensor arrangement.
• Check the 0/4–20 mA loop requirements and burden.
• Check the buffered 2–10 V signal interface.
• Confirm relay contact loads and alarm wiring.
• Verify the available +24 VDC supply range.

02 / DIRECT CONTACT
Need A3311-022-000?
Send the exact part number together with your required quantity and destination. Our team can check the requested configuration and arrange the next step for your order.
Sales Manager Miya zheng
Email sales@amikon.cn
Phone / WhatsApp 86-18020776792
DELIVERY
3–5 Days
WARRANTY
12 Months
PACKAGING
Brand New
DELIVERY WAY
E-packing / FedEx / EMS / TNT / DHL / UPS
PAYMENT
T/T
ORDER SUPPORT
Global Delivery
For a Faster Quotation
Please provide the following five details with your inquiry:
Part Number Quantity Destination Required Date Machine / System
After-Delivery Return & Replacement
Please contact us within 7 days if you have any question after you receiving the items.
Returned items should remain in their original condition and be accompanied by the specific reason for the return. After the returned items are received, we will arrange the applicable return or replacement for the order.
The buyer is responsible for all shipping costs incurred during the return process.
03 / BUYER QUESTIONS
A3311-022-000 FAQ
01 Is A3311-022-000 the correct configuration when the installation requires an internal eddy-current converter?
  Yes. A3311-022-000 is the internal-converter configuration of the CSI 3311 speed and key monitoring unit. The ordering configuration specifies internal eddy-current conversion, so it should be distinguished from an arrangement intended to use an external converter.
When replacing an existing unit, what should be checked before ordering A3311-022-000? 02
Confirm the exact part-number configuration, the eddy-current sensor arrangement, the available DC supply, current-loop burden, buffered-voltage connection, relay contact requirements and the physical installation conditions. The replacement should match the existing signal architecture rather than being selected only by the general “speed monitor” description.
03 Can A3311-022-000 support both analog monitoring and relay-based alarm integration?
  Yes. The unit provides two galvanically separated 0/4–20 mA current outputs and two buffered 2.0–10.0 VDC outputs, together with five make-contact relay outputs. The current outputs are specified as open-circuit and short-circuit protected, with a maximum burden of 500 Ω. Relay contacts are rated up to 48 VDC, 1 A and 50 W within the stated limits.
Why would A3311-022-000 be selected instead of another CSI 31xx monitoring model? 04
The selection depends on the measured variable. A3110 is associated with shaft vibration, A3120 and A3125 with bearing vibration, and A3210 with shaft position. A3311 is specifically oriented toward speed and key-signal measurement. Therefore, A3311-022-000 is appropriate when rotational speed and key information are the required measurement functions.
05 Is A3311-022-000 suitable for high-speed rotating equipment where the required speed range approaches 65,535 rpm?
  The specified configurable measurement range reaches a maximum of 65,535 rpm, with the actual usable range limited by the input frequency. Because the frequency range is 0–20 kHz, the complete sensor, target and pulse-frequency arrangement should be checked against the actual shaft-speed requirement before ordering.
