BENTLY NEVADA
CB2W100-125
2-Wire Transducer Interconnect Cable
A 125-foot interconnect cable configuration for Bently Nevada 2-wire transducer applications, designed as part of the signal connection path between the transducer and monitoring equipment.
|
CABLE CONFIGURATION
125'
38.1 m approximately
Standard length configuration
|
|
01 / LENGTH
125 ft
Approximately 38.1 m
|
02 / SIGNAL PATH
2-Wire
Transducer interconnect application
|
03 / CABLE TYPE
Shielded
Twisted-pair cable configuration
|
|
◆
|
Built for Reliable Signal Connection
The CB2W100-125 is a Bently Nevada interconnect cable configuration intended for 2-wire transducer connections. The 125-foot version provides approximately 38.1 meters of cable length, making it suitable where the transducer-to-monitoring equipment connection requires an extended cable run.
The cable configuration uses a shielded twisted-pair construction and is designed for use within the associated Bently Nevada transducer connection architecture.
|
| Part Number | CB2W100-125 |
| Cable Application | Cable for 2-wire transducer |
| Length | 125 ft / approximately 38.1 m |
| Cable Construction | Shielded twisted pair |
|
Where CB2W100-125 Fits
In a machinery monitoring installation, the interconnect cable forms the physical signal path between the transducer and the monitoring system. The CB2W100-125 is particularly relevant when a 125-foot cable length is required for a 2-wire transducer connection.
|
WHY THE PART NUMBER MATTERS
CB2W100-125
The suffix 125 corresponds to the 125-foot cable length configuration.
LENGTH
125 ft / 38.1 m |
|
DELIVERY
3–5 Days
Fast response for spare-part requirements
|
WARRANTY
12 Months
After-sales support for your purchase
|
PACKAGING
Brand New
Prepared for industrial spare-part supply
|
 |
 |
|
Need CB2W100-125?
Send the key purchasing details and we can respond more efficiently to your spare-part requirement.
|
CONTACT DIRECTLY
Sales Manager: Miya Zheng
|
||||||
