01 / PRODUCT IDENTIFICATION
3300 XL 50 mm Sliding Probe Clamp Set
|
| Bently Nevada 330879-03-00 is the clamp-set execution used with the 3300 XL 50 mm sliding probe bracket arrangement. Option 03 supplies two clamps for complementary-input differential-expansion applications, with one right-exit and one left-exit clamp. Option 00 means that a differential-expansion mounting bracket is not included. |
INSTALLED FAMILY
3300 XL 50 mm Proximity System
|
|
+
|
02 / FUNCTIONAL DESCRIPTION
Signal or Power Role in the Installed System
|
| FUNCTIONAL PATH | The two clamps retain and position a pair of 50 mm proximity probes around a differential-expansion target. Opposite clamp exits allow both probe cables to route toward the same side of the complementary-input mounting arrangement. The sliding carriage and bracket are selected separately to suit the turbine geometry. |
|
+
|
03 / TECHNICAL SPECIFICATIONS
Key Configuration Details
|
|
+
|
04 / COMPATIBILITY AND RELATED MODELS
Select by Function, Suffix and Installed Platform
|
|
+
|
05 / MODEL COMPARISON AND REPLACEMENT GUIDE
Replacement Checks Before Shutdown
|
| Identity: match the complete suffix and style. | Connection: verify the base, terminal block, adapter and field wiring. | System fit: confirm platform release, channel behavior and environmental execution. |
| Contact us within seven days if a concern appears after delivery. | Return the item in its original condition with the reason stated. Resolution follows receipt and inspection. | Return-related transport costs are arranged by the buyer. |
|
+
|
06 / TECHNICAL FAQ
Five Checks Buyers Should Complete
|
| 01 |
330879-03-00 - What is the most important ordering check?
Match the complete model, suffix code and style with the installed unit; the base model alone is not sufficient.
|
| 02 |
330879-03-00 - Can a related model be used as a direct substitute?
Only after channel count, signal type, isolation, termination, environmental execution and supported system release are confirmed.
|
| 03 |
330879-03-00 - What should be recorded before removal?
Record slot position, terminal assignment, field polarity, connected base or terminal block, and all visible suffix and style markings.
|
| 04 |
330879-03-00 - What should be tested after installation?
Verify seating, wiring, power and diagnostics, then commission each affected channel under controlled conditions.
|
| 05 |
330879-03-00 - What should be sent with a quotation request?
Send the full catalog code, quantity, required condition, destination and clear photos of the unit label and front connection area.
|
|
+
|
