A Bently Nevada 3300 5 mm proximity probe used as part of a proximity transducer system for non-contact measurement of rotating machinery condition, including shaft position and vibration applications.
The probe provides the sensing element used for non-contact measurement of the target surface.
The probe operates as part of the 3300 XL 5 mm transducer arrangement with its associated extension cable.
The complete transducer system uses the probe with the 3300 XL 5 mm Proximitor Sensor.
| Part Number | 330171-00-08-20-02-00 |
| Product Family | 3300 5 mm Proximity Transducer System |
| Probe Type | 5 mm Proximity Probe |
| Measurement Principle | Non-contact eddy-current proximity measurement |
| Measurement | Static shaft position and dynamic vibration |
| Additional Applications | Keyphasor and speed measurement |
| Typical Machinery | Fluid-film bearing rotating machinery |
The 3300 5 mm system is intended for measuring shaft position and vibration on machines using fluid-film bearings. The probe senses the distance between its tip and the conductive target without physical contact.
A probe replacement may become important when a machinery monitoring channel is unavailable, signal quality is compromised, or a maintenance team needs to restore the intended proximity measurement path. Loss of reliable monitoring can reduce visibility of developing machinery conditions and increase operational risk.
Our service is built around the practical needs of industrial maintenance teams. We support customers searching for automation components across multiple manufacturers and applications, with multilingual communication and a focused approach to hard-to-find parts.
To speed up your quotation, please include:
The 3500/22M 138607-01 Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
3500/22M is a Transient Data Interface Module manufactured and designed by Bently Nevada as part of the 3500 Series used for monitoring seismic activity. The 3500/22M Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
The 3500/33 16-Channel Relay Module is a full-height module that provides 16 relay outputs. You can place any number of 16-channel relay modules in any of the slots to the right of the Transient Data Interface (TDI) Module. Each output of the 3500/33 16-Channel Relay Module can be independently programmed to perform voting logic.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The 3500/60 133811-01 modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/72M Recip Rod Position Monitor meets API 618 requirements for reciprocating compressors. It measures: l Rod position l Rod drop l Hyper-compressor The four-channel 3500/72M Recip Rod Position Monitor accepts input from proximity transducers, conditions the signal to provide dynamic and static position measurements, and compares the conditioned signals with userprogrammable alarms. Each channel, depending on how you configure it, typically conditions its input signal to generate various parameters called measured values.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
