3300 XL 8 mm Proximity Probe designed for non-contact measurement within a complete proximity transducer system.
The 330101 model designation identifies the 3300 XL 8 mm probe with a 3/8-24 UNF thread and without armor. The complete ordering code defines additional configuration details such as probe length, connector/cable option and agency approval option.
The 3300 XL 8 mm probe forms part of a complete eddy-current proximity transducer system together with the matching extension cable and Proximitor Sensor. The system is intended for machinery measurements where non-contact sensing of a conductive target is required.
Proximity measurements are used in machinery condition monitoring and protection. A failed, damaged or incorrectly matched probe can interrupt the measurement chain, potentially affecting monitoring availability and increasing the risk of operating without the intended machinery protection signal.
When a plant is troubleshooting a missing or unstable proximity signal, physical probe damage, cable/connector issues, or a replacement requirement within an existing 3300 XL installation, the exact part number becomes important. Matching the complete ordering code helps maintain the intended transducer-system configuration and avoid unnecessary commissioning delays.
AMIKON supports industrial automation maintenance teams with sourcing and delivery of hard-to-find automation components, helping customers shorten the time between identification and replacement.
It is a Bently Nevada 3300 XL 8 mm proximity probe with a 3/8-24 UNF thread and without armor.
The probe operates as part of the 3300 XL 8 mm proximity transducer system, working with its compatible extension cable and Proximitor Sensor.
The full code identifies configuration details beyond the basic 330101 probe family, including length, connector/cable and approval options.
The probe is intended to operate within a compatible proximity transducer system rather than as a standalone measurement device.
Verify the complete part number and system configuration, including the probe's specified length, cable/connector arrangement and applicable approval option, so the replacement matches the existing installation.
Selected models for customers sourcing industrial control and automation components.
Our multilingual support team helps customers identify and source industrial automation components across a broad range of manufacturers. With structured order handling and a focus on efficient delivery, we aim to make urgent replacement sourcing simpler for maintenance and engineering teams.
Send the complete part number together with your quantity and application details. Our team can check your requirement and prepare a quotation.
The 3500/22M 138607-01 Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
3500/22M is a Transient Data Interface Module manufactured and designed by Bently Nevada as part of the 3500 Series used for monitoring seismic activity. The 3500/22M Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
The 3500/33 16-Channel Relay Module is a full-height module that provides 16 relay outputs. You can place any number of 16-channel relay modules in any of the slots to the right of the Transient Data Interface (TDI) Module. Each output of the 3500/33 16-Channel Relay Module can be independently programmed to perform voting logic.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The 3500/60 133811-01 modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/72M Recip Rod Position Monitor meets API 618 requirements for reciprocating compressors. It measures: l Rod position l Rod drop l Hyper-compressor The four-channel 3500/72M Recip Rod Position Monitor accepts input from proximity transducers, conditions the signal to provide dynamic and static position measurements, and compares the conditioned signals with userprogrammable alarms. Each channel, depending on how you configure it, typically conditions its input signal to generate various parameters called measured values.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
