The 3300 XL 8 mm system uses an eddy-current proximity transducer principle. Its output varies directly with the distance between the probe tip and the conductive target, making the system suitable for monitoring both shaft position and vibration.
Shaft position measurement
Shaft vibration measurement
The probe forms part of a 3300 XL 8 mm proximity transducer system, working with an appropriate extension cable and Proximitor Sensor.
The 3300 XL 8 mm proximity transducer system is primarily intended for vibration and position measurements on fluid-film bearing machines. It can also be used for Keyphasor reference and speed measurement applications.
Rotating machinery where shaft vibration or position must be observed without physical contact.
Maintenance teams may identify the exact probe when an existing 3300 XL monitoring channel requires replacement.
Loss or degradation of the proximity measurement channel can require inspection of the probe, cable, connections and associated monitoring hardware.
An unavailable or unreliable monitoring channel can reduce visibility of machinery condition and may complicate protection or maintenance decisions.
It is a 3300 XL 8 mm probe with a 3/8-24 UNF thread, 0.8-inch unthreaded length, 2.4-inch overall case length, 1.0-meter total length, standard cable and no agency approval option.
For the standard threaded 330101 probe, the first option defines the unthreaded length. The 08 configuration corresponds to 0.8 inch.
The system provides measurements of both static position and dynamic vibration. Its primary applications include vibration and position measurement on fluid-film bearing machines.
The 10 option specifies a 1.0-meter total probe length. The overall system configuration must be matched with the appropriate Proximitor Sensor arrangement.
The 02 option specifies a miniature coaxial ClickLoc connector with standard cable. The connector design uses a locking mechanism intended to prevent loosening during operation.
When an established machinery monitoring point needs a replacement, accurate part-number matching and responsive supply can help shorten the maintenance window.
Additional industrial automation components available for matching requirements.
To help us confirm the correct configuration quickly, please include the key purchasing and application details with your inquiry.
The 3500/22M 138607-01 Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
3500/22M is a Transient Data Interface Module manufactured and designed by Bently Nevada as part of the 3500 Series used for monitoring seismic activity. The 3500/22M Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
The 3500/33 16-Channel Relay Module is a full-height module that provides 16 relay outputs. You can place any number of 16-channel relay modules in any of the slots to the right of the Transient Data Interface (TDI) Module. Each output of the 3500/33 16-Channel Relay Module can be independently programmed to perform voting logic.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The 3500/60 133811-01 modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/72M Recip Rod Position Monitor meets API 618 requirements for reciprocating compressors. It measures: l Rod position l Rod drop l Hyper-compressor The four-channel 3500/72M Recip Rod Position Monitor accepts input from proximity transducers, conditions the signal to provide dynamic and static position measurements, and compares the conditioned signals with userprogrammable alarms. Each channel, depending on how you configure it, typically conditions its input signal to generate various parameters called measured values.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
