Bently Nevada 330101-00-10-10-01-05 3300 XL 8 mm Eddy-Current Proximity Probe
|
BENTLY NEVADA™ 3300 XL 8 MM
330101-00-10-10-01-05
Precision Eddy-Current Proximity Probe for Machinery Monitoring
Designed for non-contact measurement of shaft position and vibration, this 3300 XL 8 mm probe configuration is suited to machinery condition monitoring applications where reliable proximity sensing is essential.
|
PRODUCT FAMILY
3300 XL
8 mm Proximity Probe
|
|
01
3/8-24 UNF
Standard threaded probe construction for compatible mounting arrangements.
|
02
1.0 m System Length
Configured with a 1.0 meter total probe length for compact installations.
|
03
No Armor · ClickLoc
Standard cable configuration with miniature coaxial ClickLoc connector and protector.
|
| Model | 330101-00-10-10-01-05 |
| Probe Family | 3300 XL 8 mm Proximity Probe |
| Thread | 3/8-24 UNF |
| Armor | Without armor |
| Unthreaded Length | 0.0 inch configuration |
| Case Length | 1.0 inch configuration |
| Total Length | 1.0 meter |
| Cable / Connector | Standard cable with miniature coaxial ClickLoc connector and connector protector |
| Approval Option | CSA, ATEX and IECEx |
|
Measurement Capability
The 3300 XL 8 mm system produces an output voltage proportional to the distance between the probe tip and the conductive target. This enables both static position and dynamic vibration measurement.
Primary applications include vibration and position measurement on fluid-film bearing machines, together with Keyphasor reference and speed measurement applications.
|
|
|
Rotating Machinery
Suitable for proximity measurement on machines using fluid-film bearings where shaft vibration and position are important operating indicators.
|
Position Monitoring
Non-contact sensing can be used to monitor static shaft position as well as dynamic shaft movement.
|
Protection & Diagnostics
When a probe signal becomes unstable, unavailable or inconsistent, inspection of the probe, cable, connectors, target condition and gap can become an important part of troubleshooting.
|
|
Designed for Reliable Installation
The 3300 XL platform uses gold-plated ClickLoc connectors with a locking mechanism designed to prevent loosening during operation.
The probe case uses stainless steel construction, while the probe tip uses polyphenylene sulfide (PPS).
The standard probe operating and storage temperature range is -52°C to +177°C (-62°F to +350°F).
|
Supply & Service
|
Professional Customer Service Team
|
Industrial Automation Inventory
|
|
01. What type of probe is the 330101-00-10-10-01-05?
It is a Bently Nevada 3300 XL 8 mm proximity probe with a 3/8-24 UNF thread and a standard non-armored construction.
|
|
02. What measurements can the 3300 XL 8 mm system provide?
The system can measure static shaft position and dynamic vibration, and it can also be used for Keyphasor reference and speed measurement applications.
|
|
03. What is the configured total length?
This specific configuration uses a 1.0 meter total probe length.
|
|
04. Does this configuration use an armored cable?
No. The 330101 configuration is the 3/8-24 UNF version without armor. This specific part number uses the standard cable and ClickLoc connector with connector protector.
|
|
05. What should be checked when replacing this probe?
Confirm the thread arrangement, probe length, cable configuration, connector arrangement, approval option, target material and required probe gap before installation.
|
|
