| BENTLY NEVADA | Overview Specifications Application FAQ Related Inquiry |
|
ASSET CONDITION MONITORING
Bently Nevada
|
|
TYPE
Low-Frequency
|
RANGE
±196 m/s²
|
FREQUENCY
1.5–10,000 Hz
|
|
PRODUCT IDENTIFIER
200155
Accelerometer Series
01 Low-frequency vibration measurement
02 Case-mounted seismic design 03 5-pin top connector Built for demanding industrial vibration-monitoring environments.
|
|
SENSITIVITY
10.2 mV/(m/s²)
|
RESONANCE
>20 kHz
|
HOUSING
304L Stainless Steel
|
MOUNTING
3/8-24 Female
|
|
01 / CORE VALUES
Technical ProfileThe 200155 is a case-mounted seismic accelerometer developed for low-frequency vibration measurement in industrial machinery monitoring applications. Its piezoelectric sensing element converts vibration-related mechanical input into an electrical signal proportional to acceleration along the sensitive axis. |
|
| SIGNAL PATH |
01
Vibration
|
— |
02
Piezoelectric Sensing
|
— |
03
Differential Voltage
|
|
02 / FIELD APPLICATION
Where the 200155 FitsThe 200155 is intended for low-frequency acceleration-to-velocity applications using the appropriate Trendmaster ProTIM channel. The product is particularly suited to fin-fan equipment and slow-rotating shafts. A typical search for this part number occurs when a plant is troubleshooting unstable vibration readings, replacing a failed case-mounted accelerometer, or restoring monitoring on equipment where low-frequency vibration is important. |
|
| Physical Size 17.5 mm × 45.7 mm |
Typical Weight 58 g |
| Mounting Thread 3/8-24 Female |
Mounting Torque 2.7–6.8 N·m |
| Electrical Connector Top-mounted 5-pin connector |
Excitation Voltage 4.7–5.5 Vdc |
| Quiescent Current <800 µA |
Output Bias Voltage +2.5 ± 0.23 Vdc |
| Cable Limit Maximum 50 ft for 200155 |
Cable Construction 4-conductor, 22 AWG, braided shield |
|
QUICK PRICE CHECK
Need the 200155-00-CN for an active maintenance job?
Send the part number and quantity first. We can then check the current quotation and delivery arrangement with you.
|
REQUEST PRICE |
| 01 |
How do I know whether 200155-00-CN is the right accelerometer for my application?
Start with the existing monitoring architecture rather than the sensor appearance alone. The 200155 is intended for low-frequency acceleration-to-velocity applications on compatible Trendmaster ProTIM channels. It is especially associated with fin-fan equipment and slow-rotating shafts. If the existing channel is configured for a different accelerometer type, the signal response may not be correct.
|
| 02 |
Why would a maintenance engineer search for this exact part number during a shutdown?
A common reason is the need to restore an existing vibration measurement point without changing the surrounding monitoring arrangement. If an installed accelerometer has failed, readings have become unstable, or a machine monitoring point has been taken out of service, matching the existing part number can reduce uncertainty during replacement.
|
| 03 |
What happens if the 200155 is connected to an unsuitable channel or monitor?
The technical specification warns that using the 200155 with monitors or TIMs other than the compatible configurations can produce false readings. This matters because an apparently normal electrical signal does not necessarily mean that the vibration measurement is valid. Channel configuration should therefore be checked before replacement.
|
| 04 |
Does mounting method matter when replacing a 200155 accelerometer?
Yes. The sensor uses a 3/8-24 female mounting thread and supports multiple mounting arrangements. The installation needs to transmit the machine vibration faithfully to the transducer. Poor installation can degrade performance or create a signal that does not represent actual machine vibration.
|
| 05 |
What should I send when I need a fast quotation for 200155-00-CN?
Please provide the exact Part Number, Quantity, Destination, Required Date, and Machine/System. For replacement work, it is also useful to mention whether the existing installation uses a Trendmaster ProTIM low-frequency acceleration-to-velocity channel. This allows the quotation to be handled with the actual application in mind rather than treating the part number as an isolated item.
|
|
06 / PROCUREMENT
Need a Price for 200155-00-CN?For a quotation, please send the exact Part Number, Quantity, Destination, Required Date, and Machine/System. Delivery: 3–5 days |
