BENTLY NEVADA / PROXIMITY SYSTEM
102045-040-01-05
3300 Series Proximity Transducer System Component
Non-contact Measurement Vibration Monitoring Rotating Machinery
|
BN
3300 SERIES
|
|
01
SYSTEM FAMILY
3300 Series
|
02
MEASUREMENT METHOD
Eddy Current
|
03
PRIMARY USE
Vibration / Position
|
|
Product Details
The Bently Nevada 102045-040-01-05 is associated with the Bently Nevada 3300 Series proximity monitoring architecture. The 3300 XL proximity transducer system uses a probe, extension cable and Proximitor sensor to provide non-contact measurement of rotating machinery conditions.
|
|
Technical Highlights
|
Extension Cable Architecture
3300 XL Extension Cable
The 3300 XL system uses a miniature coaxial connector arrangement and 75 Ω cable construction. The official system drawing specifies a maximum cable diameter of approximately 3.7 mm for the cable itself, with armored construction available around the cable.
SYSTEM CONNECTION
PROBE → EXTENSION CABLE → PROXIMITOR SENSOR
Target Signal Monitoring
|
|
Where This Component Matters
In rotating equipment, proximity measurement is valuable when operators need to observe shaft movement without introducing mechanical contact. Bently Nevada's 3300 XL 8 mm proximity system is designed for vibration and position measurements on rotating machinery, including fluid-film bearing machines.
|
|
When Operators Usually Search for This Part
For critical rotating machinery, loss or degradation of a proximity measurement channel can affect the availability of vibration and position monitoring. In a protection-oriented installation, resolving a suspect sensing channel quickly can therefore help reduce the risk of extended diagnostic downtime. |
|
Frequently Asked Questions
|
|
Need a Price for 102045-040-01-05?
Send us the exact part number and quantity. We will check the available option and provide a quotation according to your destination and required date.
|
|
