Allen-Bradley ACS510 low-voltage general-purpose Variable Frequency Drives

Allen-Bradley ACS510
Allen-Bradley ACS510
Allen-Bradley ACS510

Allen-Bradley ACS510 low-voltage general-purpose Variable Frequency Drives

Calculate shipping
Quotation Request


ABB
DRIVE
STANDARD DRIVE

ACS510

Pump and Fan
Variable-Torque Control
ABB ACS510 is a three-phase standard drive family for variable-torque applications, with integrated process-control functions for pumps and fans.
380-480 VThree-phase supply 1.1-160 kWFamily power range 48-63 HzInput frequency
Application strengths
PID process control, pump and fan macros, energy optimization and coordinated multi-pump operation. Select the exact current, power, frame and enclosure code for the motor and site.		 International Delivery on the Day
Quick Response Support
Intercontinental Cooperation Network



SELECTED ABB ACS510 GENERAL PURPOSE DRIVES

ACS510-01 SELECTED 380-480 V MODELS

This page covers ten selected ACS510-01 drive models for variable-torque pump and fan applications. The models presented here are rated from 9.4 to 88 A and from 4 to 45 kW, using frame sizes R1 through R4. They form part of the wider ACS510 family, which includes additional ratings beyond the catalog numbers shown on this page. Integrated application functions support motor speed regulation, process feedback control and coordinated multi-pump operation.


380-480 V 9.4-88 A 4-45 kW R1-R4

INPUT DC LINK INVERTER MOTOR PROCESS
MATCH THE DRIVE TO THE MOTOR AND APPLICATION
Send the motor nameplate current, supply voltage, duty, enclosure and required control options.
 EMAIL MIYA WHATSAPP 86-18020776792
SELECTED MODEL RATINGS

The Ten Requested Models Across Four Frame Sizes

TYPE CODE RATED CURRENT TYPICAL MOTOR POWER FRAME
ACS510-01-09A4-4 9.4 A Pump / fan motor 4 kW R1
ACS510-01-012A-4 11.9 A Pump / fan motor 5.5 kW R1
ACS510-01-017A-4 17 A Pump / fan motor 7.5 kW R2
ACS510-01-025A-4 25 A Pump / fan motor 11 kW R2
ACS510-01-031A-4 31 A Pump / fan motor 15 kW R3
ACS510-01-038A-4 38 A Pump / fan motor 18.5 kW R3
ACS510-01-046A-4 46 A Pump / fan motor 22 kW R3
ACS510-01-060A-4 60 A Pump / fan motor 30 kW R4
ACS510-01-072A-4 72 A Pump / fan motor 37 kW R4
ACS510-01-088A-4 88 A Pump / fan motor 45 kW R4

The kilowatt values are typical motor ratings for pump and fan duty. Select the drive primarily from motor full-load current and actual load behavior. Apply any required derating for ambient temperature, altitude, switching frequency and installation conditions.

Pump and fan control

Variable-speed operation supports demand matching, softer mechanical starts and reduced throttling losses. Built-in process control can regulate pressure, flow, level or temperature from a feedback signal.		 Application functions

Application macros simplify common I/O assignments. PID control, sleep and wake behavior, flying start and pump/fan coordination help adapt the drive to variable-torque systems.		 Installation checks

Confirm mains system, branch protection, cable size, motor insulation, grounding, enclosure airflow, EMC requirements, fieldbus option and any braking or bypass arrangement.
SYSTEM RELATIONSHIP

From Three-Phase Supply to Controlled Process

380-480 V SUPPLY

Protection, isolation and grounding		 → ACS510-01 DRIVE

Rectification, DC link and controlled motor output		 → MOTOR + PROCESS

Pump, fan, pressure, flow or ventilation duty
R1-R2
Used by the requested 4 to 11 kW models shown on this page.		 R3
Used by the requested 15 to 22 kW models shown on this page.		 R4
Used by the requested 30 to 45 kW models shown on this page.
Series advantage: The common control approach makes it easier to standardize parameter handling and operator training across several motor sizes. Electrical accessories, mechanical dimensions, cooling demand and branch protection still change with the frame and rating.

Amikon support team

QUALITY
RELIABILITY
FAST COORDINATION
 Drive product inspection

Industrial parts coordinated for faster recovery
Amikon supports current equipment and long-running installed bases through responsive communication, stock coordination and global shipment support.
TRUST   /   ORDER TRACKING   /   GLOBAL REACH
 Warehouse shipment operations

WAREHOUSE SUPPORT
MULTIBRAND COVERAGE
NO HIDDEN HANDLING FEES
REQUEST THE CORRECT ACS510 CURRENT RATING
Send the motor nameplate current, supply voltage, duty, enclosure and required control options.
 EMAIL MIYA WHATSAPP 86-18020776792
PURCHASING FAQ

ACS510-01 Selection Questions

Can ACS510-01-09A4-4 be selected only from a 4 kW motor rating?
No. Confirm the motor nameplate current, load type, supply voltage, ambient conditions and required overload margin. The 4 kW value is the typical pump and fan rating.		 Can ACS510-01-012A-4 through ACS510-01-088A-4 share one parameter set?
They share a common control concept, but motor data, current limits, acceleration, protection, PID tuning and application I/O must be commissioned for each motor and process.
Can ACS510-01-017A-4 replace ACS510-01-012A-4 without cabinet changes?
The higher rating moves from frame R1 to R2. Check mounting dimensions, airflow, cable terminals, branch protection and the existing enclosure layout before substitution.		 Why do ACS510-01-031A-4, ACS510-01-038A-4 and ACS510-01-046A-4 share frame R3?
They use the same frame class but have different current and power ratings. Protective devices, conductors and thermal loading must follow the exact type code.
What should be supplied for ACS510-01-060A-4, ACS510-01-072A-4 or ACS510-01-088A-4 quotation?
Provide the exact type code, input voltage and frequency, motor current and power, pump or fan duty, enclosure rating, altitude, ambient temperature, communication option, bypass arrangement and braking requirement.
Return and replacement support: Contact us within seven days after receipt if an issue is found. Keep the item in its original condition and state the return reason. A return or replacement can be arranged after inspection; shipping charges remain the buyer's responsibility.
RELATED INDUSTRIAL MODELS

Broader Supply Directory

F01U033343 NBG-12LX MRI-M500S 3UG4614-1BR20
MTN631619 XP10BKB/DC DIN-AP2 EM-07K
SB-DIM4c3A-DN SA-043F AJ65BTB2-16D SB-3R-TC
GHQ6310062R0111 DDNP1501 TSXPSY2600 H3DE-S1
CC-PDIL51 CC-PDOB51 TK-PRR021 TC-PRR021
TC-CCR013 PM851AK01 3BSE066485R1 PM861AK01 3BSE018157R1 IS230TCATH1A
IS220UCSAH1A IS210MVRCH1A IS210DTAIH1A IS210DTAOH1A
IS210DTCIH1A AAI835-S50/K4A00 ADV551-P60 1756-EN2T
1756-EN2TR 1756-EN3TR 1756-EN4TR SENSION156
DR2800 LICO500 PHC281 PHC805
DR4900 LQV157 X20CP1584 X20SL8000
X20BC8084 X20DO8332 X20CP1483 7MH4920-0AA01
6SE7032-1HB87-2DA1 6SE7031-6EB87-2DA1 6EP1437-3BA00 6SE7032-7EB87-2DA1
KJ2201X1-BA1 KC4011X1-BW1 KC4011X1-BZ1 KJ4006X1-BD1
CE4035S2B5 VE4035S2B5 CE4003S2B6 A3C40173228
SEND YOUR NEXT INDUSTRIAL PART NUMBER TO MIYA
Send the motor nameplate current, supply voltage, duty, enclosure and required control options.
 EMAIL MIYA WHATSAPP 86-18020776792
Sales manager: Miya Zheng   |   Email: sales@amikon.cn   |   Phone / WhatsApp: 86-18020776792
Hot Tags : Allen-Bradley ACS510 ACS510 Variable Frequency Drives Allen-Bradley Variable Frequency Drives Allen-Bradley VFDs ACS510-01-09A4-4 manual ACS510-01-09A4-4 pdf
