ALLEN-BRADLEY · KINETIX 5700
2198-P070

Kinetix 5700 DC Bus Supply
A compact DC bus supply for the Kinetix 5700 multi-axis servo platform, specified for 480 VAC three-phase input and a 25 A continuous output rating.

OUTPUT
25 A
Continuous

PEAK
70 A
Peak output
480
VAC
3Φ
Three-phase
55
mm width






01 / PRODUCT PROFILE
Built for the
DC-bus architecture

FUNCTION
DC Bus Supply
Kinetix 5700 servo system power architecture
INPUT
480 VAC · 3-phase
Designed within the Kinetix 5700 power-supply family
25 A CONTINUOUS
Continuous output current rating
70 A PEAK
Peak output current rating


CATALOG NUMBER
2198-P070
OUTPUT CURRENT
25 A
PEAK CURRENT
70 A
MODULE WIDTH
55 mm


02 / SERIES STRUCTURE
Kinetix 5700 shared DC-bus platform

The 2198-P070 belongs to the Kinetix 5700 DC Bus Supply family. Within this family, the DC bus supply works with Kinetix 5700 axis modules to build a multi-axis servo system. The 2198-P070 provides a 25 A continuous output rating and 70 A peak output rating in a 55 mm module width.
A
DC Bus Supply
 →
B
Axis Module
 →
C
Servo System
5700
Related DC Bus Supply family
2198-P031
2198-P070
2198-P141
2198-P208
The family provides different current ratings for different Kinetix 5700 system power requirements.


03 / SYSTEM FIT
Where the
2198-P070 fits
The module is intended for Kinetix 5700 servo systems where a DC bus supply is required to support the connected axis modules.
◈
Multi-axis motion
Suitable for Kinetix 5700 configurations using shared DC-bus architecture.
◎
Servo platforms
Designed as the power-supply element of the Kinetix 5700 servo system.
◇
Compact installation
55 mm module width supports compact Kinetix 5700 cabinet layouts.


04 / PROCUREMENT
Ready to source
2198-P070?

For quotation, please provide the part number, quantity, destination, required date and machine/system information so the order can be checked efficiently.
EMAIL
sales@amikon.cn 		PHONE / WHATSAPP
86-18020776792
SALES MANAGER Miya zheng


05 / BUYER QUESTIONS
2198-P070 FAQ

01 · Is 2198-P070 the correct DC bus supply when my Kinetix 5700 system requires a 25 A continuous rating?
Yes, the 2198-P070 is the 25 A DC Bus Supply model in the Kinetix 5700 family. It is specified with a 25 A continuous output rating and a 70 A peak output rating. System selection should also account for the connected axis modules and total system requirements.
02 · Can 2198-P070 be selected as a standalone servo drive?
No. The 2198-P070 is a DC Bus Supply rather than an axis module. A valid Kinetix 5700 servo system requires a DC Bus Supply together with an appropriate axis module configuration.
03 · What should I check before replacing an existing Kinetix 5700 DC bus supply with 2198-P070?
Check the existing catalog number, system voltage arrangement, required continuous and peak current, connected axis modules, available panel space and the overall DC-bus configuration. The 2198-P070 is specifically a 55 mm wide Kinetix 5700 DC Bus Supply.
04 · Does 2198-P070 use the same current class as the other Kinetix 5700 DC bus supplies?
No. The Kinetix 5700 DC Bus Supply family includes different current ratings. The 2198-P070 is the 25 A continuous / 70 A peak model, while other family members provide different current capabilities. The replacement should therefore be matched to the system's electrical requirements rather than selected only by physical appearance.

05 · Why does 2198-P070 need to be evaluated together with the complete Kinetix 5700 configuration?
Because the DC Bus Supply is one part of the multi-axis servo architecture. The system configuration includes the DC Bus Supply, axis modules and the associated DC-bus requirements. Confirming the complete configuration helps avoid selecting a power-supply rating that does not match the connected system.
