2198-D032-ERS3
KINETIX 5700 DUAL-AXIS INVERTER
|
MATCH THE CODE
VERIFY THE REVISION PLAN THE REPLACEMENT |
|
Dual-Axis Servo Inverter
Allen-Bradley 2198-D032-ERS3 is a Kinetix 5700 dual-axis inverter for EtherNet/IP-integrated motion systems. It supplies two servo axes from the common DC bus and combines high-performance motion control, drive diagnostics and integrated safety functions within the Kinetix 5700 architecture.
|
REQUEST A QUOTE → |
| ▣ | Technical Specifications |
| Drive family | Kinetix 5700 |
| Module type | Dual-axis inverter |
| Continuous output current per axis | 13.0 A rms |
| Continuous output current per axis | 18.3 A 0-pk |
| Peak output current per axis | 32.5 A rms |
| PWM frequency | 4 kHz |
| Velocity-loop bandwidth | Up to 400 Hz |
| Current-loop bandwidth | Up to 1000 Hz |
| Network | EtherNet/IP with CIP Motion |
| Safety designation | ERS3 integrated safety feature set |
|
SYSTEM PATH / ENGINEERING CHECK
Functional Role & System Integration
The dual-axis inverter operates from the Kinetix 5700 DC-bus system and communicates with a compatible Logix controller over EtherNet/IP. Axis sizing must include motor and feedback compatibility, continuous and peak current, duty cycle, bus capacity, input power, accessory modules, safety architecture and firmware compatibility.
|
IDENTIFY ISOLATE INSTALL VALIDATE |
|
Experienced support for exact-code matching and international coordination.
|
Careful inspection and code confirmation before dispatch.
|
Urgent dispatch options help limit production delays.
|
|
1
|
How many axes does the module control?
It is a dual-axis inverter and supports two servo axes.
|
|
2
|
What is the continuous current per axis?
The rating is 13.0 A rms per axis.
|
|
3
|
Can it operate as a complete standalone drive?
No. It is part of a properly engineered Kinetix 5700 power and control system.
|
|
4
|
Can an ERS4 unit replace an ERS3 automatically?
No. Safety functions, controller project, firmware and validation requirements must be reviewed.
|
|
5
|
What should be checked before selection?
Confirm motor data, feedback, current profile, bus capacity, accessories, network and safety requirements.
|
|
Need price, lead time or revision confirmation?
Send the complete catalog code, quantity and destination for a focused response.
|
CONTACT AMIKON |
