I/O Scan Time Per Rack |
10 ms at 57.6 kbits/s, 7 ms at 115.2 kbits/s, 3 ms at 230.4 mbits/s |
|
Max I/O Chassis Extended Local |
0 |
|
Max I/O Chassis Universal Remote |
32 Max. Per I/O Link |
|
RS-232-C/422-A/423- A Ports |
1 |
|
Control Coprocessor Expansion Port |
Yes |
Need help? We're here to assist you!
Can't find your exact part number? Our experienced sales and customer service teams are here to help.
|
Professional contact channel |
|
Sales Manager：Miya zheng |
|
E-mail: sales@amikon.cn |
|
Phone: +86-18020776792（whatsapp） |
We are spare parts specialists in industrial automation
|
Inventory |
A large number of new and discontinued parts with a wide range of brand names. |
|
Economic Benefits |
Competitive Prices and Specific Distributor Discounts |
|
Reliability |
Each product is tested and guaranteed for at least 12 months |
|
Speed |
Rapid response, efficient delivery. |
|
Professional |
Solid business organization, well-trained engineers |
|
International |
Global network of partners and preferred suppliers |
Overview
The 1785-L80B is an Allen-Bradley enhanced PLC5 Programmable Logic Controller (PLC). This controller has an embedded user memory of 100,000 Words and comes with multiple communication interfaces such as four (4) DH+/Remote I/O (Adapter or Scanner), one (1) serial port configurable for RS-232, -423, and RS-422A compatibility, and two (2) programming terminals. It can accommodate up to 3072 any mix or 3072 input and 3072 output in complimentary mode.
Technical specifications for 1785-L80B
|
Manufacturer |
Allen Bradley |
|
Category |
PLCs |
|
Product Line |
PLC 5 |
|
Part Number |
1785-L80B |
|
UPC |
612598137213 |
|
Weight |
3.00 lbs (1.36 kg) |
|
Max I/O Chassis Total |
93 |
|
Max Total I/O |
3072; any mix or 3072 in + 3072 out |
|
Module Type |
PLC5 Processor |
|
Communication Ports |
Four (4) DH+/Remote I/O (Adapter or Scanner), One (1) serial port configurable for RS-232 and 423 and RS-422A compatible and Two (2) programming terminals. |
|
Supported Protocols |
DF1, ASCII, Data Highway Plus (DH+), Remote I/O (RIO) |
|
Controller Memory |
up to 64KWords |
|
Controller Memory expansion |
1785-ME16 with 16K Words, 1785-ME32 with 32KWords, 1785-ME64 with 64KWords |
|
Max. number of I/O racks |
32 |
|
Battery |
1770-XYC |
|
Controller Redundancy |
Supported |
|
Power Dissipation |
12 W |
|
Backplane Current draw |
2.3 A |
|
Processor |
PLC-5/80 |
|
Max User Memory Words |
100 Kilowords |
|
Battery-Backed Static RAM |
Yes |
|
EEPROM Program Backup Option (using 1785-ME16, -ME32, -ME64, and -M100) |
Yes |
|
Protected Memory |
No |
|
Max Analog I/O |
3072 |
Features
|
High I/O Capacity |
Supports up to 3072 I/O points for large automation systems |
|
Large Memory |
Integrated 100,000-word user memory for complex control programs |
|
Multiple Communication Channels |
Includes four DH+/Remote I/O communication channels |
|
Flexible Communication Modes |
Channels can operate as Remote I/O scanner, adapter, or DH+ interface |
|
Serial Communication Port |
One optically isolated RS-232C serial port supporting DF1 and ASCII protocols |
|
Extensive Networking |
Supports communication with up to 93 I/O chassis and 32 Remote I/O racks |
|
DH+ Networking |
Enables peer-to-peer PLC communication and remote programming |
|
Front Panel Diagnostics |
Multiple LED indicators for battery, processor, communication, force status, and channel activity |
|
High-Speed Communication |
DH+ communication speeds up to 230.4 kbps |
|
Wide Chassis Compatibility |
Compatible with multiple 1771 PLC-5 chassis configurations |
Applications
The 1785-L80B PLC controller is commonly used in:
l Process automation systems
l Oil and gas facilities
l Power generation plants
l Water and wastewater treatment
l Manufacturing production lines
l Material handling systems
l Heavy industrial machinery
l Distributed control systems requiring extensive Remote I/O communication
FQA
Q: What is the function of the 1785-L80B controller?
A: The 1785-L80B functions as the main processor in a PLC-5 automation system, controlling I/O operations and managing communication between industrial devices.
Q: How many communication ports are available on the 1785-L80B?
A: The controller includes four DH+/Remote I/O communication channels and one serial communication port.
Q: Which communication protocols does the serial port support?
A: Channel 0 supports DF1 Full-Duplex, DF1 Half-Duplex, DF1 Half-Duplex Slave, and ASCII communication protocols.
Q: What is the maximum I/O capacity of the 1785-L80B?
A: The 1785-L80B supports up to 3072 total I/O points in industrial automation applications.
Q: Which chassis are compatible with the 1785-L80B?
A: The controller can be installed in 1771-A1B, 1771-A2B, 1771-A3B, 1771-A3B1, and 1771-A4B PLC-5 chassis.
