The 1784-KTCX15 is a ControlNet communication interface card under Allen Bradley's PLC 5 series, designed to provide robust connectivity options. It accommodates both 16-bit ISA and 32-bit EISA bus types, featuring dual BNC connectors for redundancy and an RJ-45 NAP connector for additional networking capabilities. |
|
|
Manufacturer |
Allen Bradley |
|
Product Type |
ControlNet Communication Interface Card |
|
Product Line |
PLC 5 |
|
Part Number |
1784-KTCX15 |
|
Weight |
1.00 lbs (0.45 kg) |
Details
|
DetaiBus Compatibility |
16-bit ISA, 32-bit EISA |
|
Connectors |
2 BNC (redundant), 1 RJ-45 NAP |
|
Memory Requirement |
16 KB dual-port RAM |
|
Data Transfer Rate |
5 Mbps |
|
Network Protocol |
ControlNet (CIP) |
|
Redundant Media Support |
Dual BNC channel redundancy |
|
Status Indicators |
LEDs for network status/diagnostics |
|
Power Requirement |
5 V DC from host bus |
|
Power Consumption |
640 mA max current draw |
|
Isolation Voltage |
1500 V AC galvanic isolation |
|
Maximum Installations |
Up to 4 cards per host |
|
Address Configuration |
DIP switches set memory and I/O base addresses |
Feature
|
Feature |
Description |
|
ControlNet Communication |
Provides reliable ControlNet network connectivity for PLC-5 systems |
|
ISA and EISA Compatibility |
Supports both 16-bit ISA and 32-bit EISA bus types |
|
Dual BNC Connectors |
Enables redundant network connections for improved reliability |
|
RJ-45 NAP Port |
Allows easy network access for diagnostics and maintenance |
|
High-Speed Data Exchange |
Supports efficient industrial communication and control |
|
Industrial-Grade Design |
Built for demanding automation environments |
FQA
|
Questions |
Answer |
|
What is the main purpose of the 1784-KTCX15 module? |
The 1784-KTCX15 is a ControlNet communication interface card used to connect PLC-5 systems and industrial computers to ControlNet networks for high-speed data exchange. |
|
Which bus types are supported by the 1784-KTCX15? |
The module supports both 16-bit ISA and 32-bit EISA bus architectures. |
|
What communication speed does the 1784-KTCX15 support? |
The module supports a data transfer rate of 5 Mbps using the ControlNet (CIP) protocol. |
|
Why are there two BNC connectors on the module? |
The dual BNC connectors provide redundant communication channels to improve network reliability and reduce downtime. |
|
How is the module configured during installation? |
Memory and I/O base addresses can be configured using onboard DIP switches for easy setup and integration. |
