Designed for the power-distribution architecture of ABB robotic control assemblies, PDB-03 provides a central power-distribution point within the control cabinet. It is the newer replacement designation associated with PDB-02 and is intended for applications where the correct cabinet configuration and associated options have been verified.
PDB-03 is the newer replacement product associated with PDB-02, part number 3HNA023093-001.
|
PRODUCT ID
3HNA031006-001 |
TYPE
PDB-03 |
FUNCTION
Power Distribution |
SYSTEM
ABB Robotics IRC5 |
| Manufacturer | ABB |
| Product ID | 3HNA031006-001 |
| ABB Type / Product Name | PDB-03 |
| Equipment Role | Power and distribution board for robotic control assemblies |
| Associated Platform | ABB Robotics IRC5 control cabinet applications |
| Replacement Relationship | PDB-03 replaces PDB-02, 3HNA023093-001 |
| Dimensions | Approx. 435 × 181 × 120 mm |
| Net Weight | Approx. 5.9 kg |
PDB-03 belongs to the power-distribution section of ABB robotic control assemblies. Its role becomes especially important when a cabinet has to be restored after a power-distribution fault rather than after a motion-program or mechanical fault.
In a production environment, symptoms around this section can present as loss of cabinet power to downstream assemblies, failure of the robot control system to complete its normal startup sequence, or repeated interruption of robot operation. The exact symptom depends on the cabinet configuration and the electrical fault involved.
For maintenance teams, the practical concern is downtime: a failed power-distribution board can keep an otherwise serviceable robot unavailable until the cabinet power path is restored. This is why matching the exact board number and cabinet configuration before ordering is critical.
PDB-03 is commonly searched when the maintenance requirement points specifically to the power-distribution board inside an ABB robotic cabinet.
PDB-02 Replacement PathABB identifies PDB-03, 3HNA031006-001, as the replacement product for PDB-02, 3HNA023093-001. A direct replacement decision should still be made against the actual cabinet configuration rather than by model name alone. |
AEP Option CheckWhen the robot configuration includes the Additional Energy Pack option F1210, the replacement arrangement also requires attention to cable 3HNA031801-001. Confirm this option before placing a replacement order. |
Amikon supports industrial automation maintenance teams with sourcing for PLC, DCS, robotic and control-system spare parts.
Amikon focuses on industrial automation PLC modules, control assemblies, robotic spare parts and specialized replacement components, with an emphasis on helping maintenance teams shorten procurement cycles and reduce equipment downtime.
Our product scope covers ABB AC800F / AC800M, ABB robotic spare parts, HIMA, ICS Triplex Trusted systems, Triconex, Woodward, GE turbine-control components, Yokogawa CS3000, Bently Nevada 3500 monitoring systems, Emerson DeltaV and other industrial automation platforms.
|
ORDERING DETAILS
Built Around the Maintenance WindowTo prepare an accurate quotation, please provide: Part Number
Quantity
Destination
Required Date
Machine / System
|
SUPPLY TERMS
Delivery & Warranty
|
ABB identifies 3HNA031006-001 PDB-03 as the replacement product for 3HNA023093-001 PDB-02. The replacement should nevertheless be checked against the actual cabinet configuration because an installation can include additional options that affect the replacement arrangement.
Yes. When the robot includes the Additional Energy Pack option F1210, the replacement arrangement also calls for cable 3HNA031801-001. This should be checked before ordering so that the cabinet restoration does not stop because of a missing associated component.
Verify the complete part number 3HNA031006-001, the existing board designation, the robot/control-cabinet configuration, and whether option F1210 is present. Providing the machine or system together with the required date also helps avoid a replacement that does not match the intended cabinet arrangement.
PDB-03 is part of the cabinet power-distribution architecture. If the fault is located in this section, downstream control assemblies may not receive the required power path and the robot can remain unavailable even when the mechanical robot itself is serviceable. Correct fault isolation should be completed before replacing the board.
Yes. The listed PDB-03 dimensions are approximately 435 × 181 × 120 mm with a listed net weight of approximately 5.9 kg. These figures matter when planning cabinet access, handling and replacement work, particularly when maintenance must be completed inside an existing robot control cabinet.
