Model: NPOW-02 3535000901
Description: Control Module
Delivery: DHL/FEDEX/UPS/TNT/ARAMEX
|
Contact |
|
Whatsapp/mobile:86-18020776792 Email : sales@amikon.cn |
|
Description |
|
The ABB NPOW-02 (3535000901) is a 24 V DC, 10 A switch-mode power-supply module for the S800 I/O family, delivering a regulated 240 W output with ±1 % tolerance and <80 mV ripple. It accepts a wide-range single-phase input of 85–264 V AC or 100–300 V DC, features active PFC (>0.95), integral primary fusing, overtemperature fold-back, and a power-good relay contact for remote diagnostics. Mounted on a 45 mm DIN-rail, the unit uses detachable spring-clamp terminals, carries CE, UL/cUL approvals, and is RoHS-compliant per 2011/65/EU. |
|
Application |
|
Main rack power – feeds redundant 24 V buses for large S800 I/O clusters in refinery units. AC 500-eCo upgrade – powers CPU, communication, and I/O modules in modular machine lines. Marine/offshore – ABS-approved supply delivers stable 24 V on drilling rigs and FPSOs. Retrofit drop-in – replaces legacy NPOW-01C units without rewiring or changing rail space. Remote diagnostics – power-good relay wired to SCADA for early warning of supply failure. |
|
Original new and one year warranty |
|
●.Packaging Details: New and Original Factory Sealed ●.Lead Time: 2-3 days ●.Supply Ability: 200 Piece/Pieces per Month ●.Payment Term: T/T Wire Transfer ●.Warranty: 12 Months Warranty ●.ShIpment : Worldwide Fast Shipment |
|
Best selling |
||
|
SPS5710 51199929-100 |
T8311C |
5205-BACNET-PDPS |
|
FC-USI-0002 V1.0 |
T8403 |
MVI56E-MNETR |
|
CC-TAON01 51306519-175 |
T8431 |
MVI56E-MNET |
|
CC-TAIX01 51308363-175 |
T8151B |
MVI56E-MNETC |
|
8C-PDIL51 51454359-175 |
T3481A |
MVI56E-MNETXT |
|
8C-TDIL11 51306858-175 |
T7481A |
MVI56-MNETC |
|
DC-TCF901 51307593-176 |
T9402 |
MVI94-MCM |
|
DC-TFB412 51307618-176 |
T8461 |
MVI94-MCM-MHI |
|
MC-TDOR62 51309150-275 |
T3420A |
MVI46-GSC |
|
TK-ORC161 |
T8110B |
MVI69-DFNT |
|
51196694-904 |
T9802 |
MVI56-GSC |
|
51401381-100 |
T9852 |
5210-DFNT-RIO |
ABB 07KT92 GJR5250500R0202 is 07 KT 92 Central Unit - 90 Series 24 VDC Power Supply CPU - 14 K FLASH EPROM twelve 24 VDC inputs Eight 24 VDC/ 0.5A transistor outputs 4 analogue inputs 12 bits resolution 2 analogue output 12 bits resolution 2 programmable RS 232 port RS 485 system The Dimensions is 24 cm x 13.7 cm x 8.5 cm, and the weight is 1 lbs 10.1 oz (0.64 kg ).
ABB DSPC172H 5731001-MP Master CPU Module DSPC172H ABB Master CPU Module Model Type: 57310001-MP/2 DSPC 172H ABB Master CPU Module, article number 57310001-MP/2. Firmware prom sub-modules. Dimensions: 5.1 cm x 25.4 cm x 25.4 cm Weight: 2 lbs 8.0 oz (1.1kg ) Series: ABB Master series module
ABB DSQC201 YB560103-AB Robot Module DSQC 201 Robot Module Model Type: YB560103-AB Dimensions: 15.2 cm x 2.5 cm x 22.9 cm Weight: 0 lbs 6.0 oz (0.2kg ) Series: ABB Robots robotics series module
ABB DSQC541 PCB Backplane Controller Card DSQC541 DSQC 541 Backplane Card module Model Type: DSQC541 DSQC 541 Input Voltage: 24V DC Operating Temperature: 0°C to 45°C Storage Temperature: -25°C to 70°C Dimensions: 19.2 cm x 12.5 cm x 22.9 cm Weight: 0 lbs 6.0 oz (0.220 kg ) Series: ABB Robots robotics series module
ABB DSQC608 3HAC12934-1 Robotics Power Supply Module DSQC608 3HAC12934-1 DSQC 608 Model Type: 3HAC12934-1 Input Voltage: 24V DC Operating Temperature: 0°C to 45°C Dimensions: 7.1x13.5x18.5cm Weight: 1.380 kg Series: ABB Robots robotics IRC5 Single series module
ABB DSQC643 3HAC024488-001/01 Controller Panel Board DSQC 643 DSQC643 3HAC024488-001/01 Model Type: 3HAC024488-001/01 Input Voltage: 24V DC Operating Temperature: 0°C to 45°C ROBOTICS FOR IRC5 CABINET WITH FLAT DOORS Dimensions: 28x20.3x2.7cm Weight: 0.400 kg Series: ABB Robots robotics controller IRC5 Single series module
ABB IMDSO14 Digital Output Slave Module Parts Type: Digital Output Slave Model Type: Bailey Infi 90 IMDSO14 Digital Output Slave, 16-Channel Open Collector, Power Requirements +5 VDC, 370 mA Dimensions: 17.8 cm x 5.1 cm x 33.0 cm Weight: 0.200 kg Series: ABB Bailey Infi 90, ABB Bailey Infi 90 and Net 90
ABB MB510 3BSE002540R1 Program Card Interface Module Parts Type: MB510 Program Card Interface Model Type: 3BSE002540R1 Country of Origin: Sweden Dimensions: 2.2x17x10.2cm Weight: 0.1400 kg Series: Advant OCS with Master, Advant Controller 450RMC
