Summary
IMHSS03 is an ABB INFI-90 hydraulic-servo module that converts processor commands into precise servo-valve current, enabling closed-loop position control of steam/gas-turbine throttle or fuel valves via LVDT feedback.
Details
|
Function: 4–20 mA servo-valve output, accepts ±10 V or 4–20 mA position demand, 12-bit D/A resolution |
|
LVDT interface: auto-selects AC or DC secondary, 2.5 kHz excitation, 0–10 V feedback, 0.1 % linearity |
|
Loop speed: 5 ms scan, PID with velocity limiting & dead-band, gain automatically tuned |
|
Redundancy: dual servo-valve drivers (active/stand-by) on one card, bumpless switch-over |
|
Isolation: 500 V field-to-logic, 30 V over-voltage protection, reverse-polarity protected |
|
Power: +5 V ±5 % @ 600 mA from INFI rack; 24 V field loop powered externally |
|
Environment: 0–70 °C, IP20 face-plate, 224 × 168 × 80 mm, 0.5 kg, 9 LEDs for status/diagnostics |
Inventory: A wide selection of new and discontinued parts from a wide range of brands.
Affordable: Competitive pricing and select dealer discounts.
Reliable: Every product is tested and comes with a minimum 12-month warranty.
Speed: Quick response and efficient delivery.
Professional: A solid business organization with highly trained engineers.
International: A global network of partners and preferred suppliers.
