ABB G2E140-PI32-10 Blower
|
DESCRIPTION |
|
Nominal voltage: 115 VAC |
|
Frequency: 50/60 Hz |
|
Speed: 2 170 rpm @ 50 Hz / 1 970 rpm @ 60 Hz |
|
Power draw: 190 W @ 50 Hz / 220 W @ 60 Hz |
|
Impeller Ø: 140 mm, housing 226 × 247 mm |
|
Protection: IP44, thermal auto-protect motor |
|
Ambient temp: –25…+70 °C (50 Hz) / –25…+60 °C (60 Hz) |
|
APPLICATIONS |
|
AC-drive cooling in ACS800-604LC liquid-cooled inverter cabinets—maintains 2 m³/min airflow across heat-sink fins, keeping IGBT junctions below 80 °C even at 150 % overload for 60 s. |
|
Forced-air cooling for 115 V servo-motor resistor banks on small CNC machines—centrifugal pressure curve handles 50 Pa back-pressure without stall, extending braking-resistor life by 30 %. |
|
Exhaust ventilation inside sealed 19" rack-mount frequency-converter panels—IP44 rating blocks oil and conductive dust, while –25 °C start-up guarantees outdoor telecom huts in winter. |
|
Retrofit blower for legacy PLC-5/1771 racks originally fitted with 120 V AC fans—identical terminal layout and 68 mm motor depth allow drop-in replacement in under five minutes, eliminating costly panel modifications. |
