ABB 3HAC032595-001 Harn-MDU/ADU 24V

ABB ROBOTICS COMPONENT

3HAC032595-001

Keep additional-drive connections dependable when uptime matters.

READY WHEN YOUR ROBOT LINE CANNOT WAIT.

KEY PARAMETERS
Type	Harn-MDU/ADU 24V
System	IRC5 high-voltage system
Position	First additional drive unit

SALES MANAGER
Miya zheng

sales@amikon.cn
WhatsApp: 86-18020776792

EMAIL OR WHATSAPP FOR A FAST PART MATCH

ABB ROBOTICS COMPONENT

3HAC032595-001

Harn-MDU/ADU 24V

3HAC032595-001 is the Harn-MDU/ADU 24V used with the first additional drive unit in the IRC5 high-voltage installation arrangement.

SYSTEM

IRC5 high-voltage systems

Exact-Part
Technical Profile

First additional drive-unit 24 V harness. The exact assembly identity matters when a robot cell is being restored after an electronic, harness or interface fault.

Part Number	3HAC032595-001
Designation	Harn-MDU/ADU 24V
System	IRC5 high-voltage system
Position	First additional drive unit
Electrical Path	MDU to ADU 24 V
Condition	Brand-new

When This Part Becomes a Priority

The harness is relevant when troubleshooting the 24 V connection between the MDU and the first ADU. A damaged, loose or incorrectly matched harness can prevent the associated drive-unit section from operating correctly and may keep an expanded motion installation unavailable.

When the relevant component cannot perform its intended role, the production cell may remain stopped until the hardware is correctly matched, replaced and returned to service.

Downtime exposure: A failed or intermittent component in this position can keep the associated robot function or production sequence unavailable. Exact-part matching can reduce the identification stage during an urgent repair.

PART MATCH DESK

Talk to Miya about 3HAC032595-001

For urgent replacement work, send the exact part number together with the machine/system context. This gives the sales team a clear starting point for matching.

EMAIL MIYA WHATSAPP MIYA

Sales manager: Miya zheng
Email: sales@amikon.cn
Phone/WhatsApp: 86-18020776792

REQUEST A MATCH

Five details. One clear quotation.

Please send the following at the time of inquiry so the requested part can be checked against the intended machine or system:

01 · Part Number

02 · Quantity

03 · Destination

04 · Required Date

05 · Machine/System

Delivery: 3–5 days Warranty: 12 months Packaging: Brand-new Delivery way: E-packing / FedEx / EMS / TNT / DHL / UPS Payment: T/T

Return / Replacement Handling

If a problem is found after receipt, please contact us within 7 days. Returned items should remain in their original condition and include the specific reason for return. A return or replacement can be arranged after the returned item is received. Return shipping costs are the buyer's responsibility.

Built for the
moments between
“stopped” and
“running”.

Fast, accurate sourcing for hard-to-find industrial automation parts — helping maintenance teams shorten the path back to production.

CONTACT MIYA · EMAIL CONTACT MIYA · WHATSAPPMiya zheng · sales@amikon.cn · 86-18020776792

PURCHASE DECISION FAQ

Questions buyers ask before committing to 3HAC032595-001

What makes 3HAC032595-001 different from the DC-bus harness used with an additional drive unit?

3HAC032595-001 is identified as the MDU/ADU 24 V harness. It serves a different electrical connection from the DC-bus harness, so selecting a replacement by connector appearance alone can lead to an incorrect part.

Why is 3HAC032595-001 associated with the first additional drive unit in an IRC5 high-voltage system?

The IRC5 installation arrangement assigns dedicated harnesses to additional drive units. The 3HAC032595-001 designation is used for the 24 V connection between the MDU and ADU in the first additional drive-unit arrangement.

What type of fault could make 3HAC032595-001 worth checking during an IRC5 breakdown?

A damaged, disconnected or electrically unreliable 24 V harness can affect the associated additional drive-unit section. In an expanded robot installation, this can prevent the affected motion system from returning to normal operation.

How can I avoid confusing 3HAC032595-001 with similar IRC5 harness part numbers?

Confirm the complete part number together with the additional-drive-unit position and the 24 V function. The first, second and third additional drive-unit arrangements use different harness part numbers.

Why is exact matching of 3HAC032595-001 important when an external axis is down?

Additional drive units can support expanded robot motion and external-axis arrangements. If the required 24 V harness is unavailable or incorrectly matched, troubleshooting can extend into a larger production delay while the drive-unit section remains unavailable.
