ABB IRB 660 / MANIPULATOR COMPONENT
3HAC022544-008
CABLE HARNESS
MANIPULATOR AXES 1–6
A dedicated cable-harness assembly associated with the ABB IRB 660 manipulator and the electrical routing serving axes 1 through 6. |
EXACT PART-NUMBER MATCHING
|
|
TECHNICAL PROFILE
Manipulator Harness ArchitectureThe 3HAC022544-008 assembly is associated with the IRB 660 manipulator cable arrangement and covers axes 1–6. Its role is centered on maintaining the electrical connection path through the robot's moving structure.
|
|
APPLICATION & MAINTENANCE
Where the Harness Becomes CriticalThe 3HAC022544-008 is associated with the ABB IRB 660 robot manipulator and the cable routing for axes 1–6. In a production cell, this places the assembly directly within the robot's moving electrical environment. Maintenance teams may look for the exact part number when intermittent axis-related behavior, cable damage, connector disturbance or harness wear points toward the manipulator wiring rather than the controller itself. Maintenance perspective:
When the robot is repeatedly cycling, an intermittent harness condition can be movement-dependent. A fault may therefore appear only during particular robot positions or motions. |
|
|
DIRECT SALES
Miya zheng
|
EMAILsales@amikon.cn | PHONE / WHATSAPP86-18020776792 |
|
PURCHASE REQUEST
Make the Part Match EasierFor a quotation on 3HAC022544-008, provide these five details so the commercial team can review the requirement efficiently.
|
SUPPLY TERMS
|
|
Why is the exact 3HAC022544-008 part number important when replacing an IRB 660 harness?
3HAC022544-008 is associated with the IRB 660 manipulator cable harness serving axes 1–6. Using the complete number helps distinguish the required assembly from harnesses assigned to other robot configurations.
When should 3HAC022544-008 become a suspect during IRB 660 troubleshooting?
If an electrical or axis-related symptom appears intermittently, especially when robot movement changes the condition, maintenance personnel may inspect the moving harness path and its associated connections.
|
What should be verified before ordering 3HAC022544-008 for an older robot?
Verify the complete part number on the existing assembly and confirm the robot model. This is particularly useful when several harness assemblies appear similar in a maintenance inventory.
Why can a 3HAC022544-008 harness problem appear only during certain robot movements?
The harness operates within the moving manipulator environment. A developing cable or connection problem may therefore change with position, movement and mechanical loading rather than remaining continuously present.
How can having 3HAC022544-008 ready reduce repair downtime?
An exact part number gives purchasing and maintenance teams a precise target for quotation and replacement planning, reducing the time spent comparing similar harness assemblies during an urgent robot repair.
|
|
