YOKOGAWA ADV569-P00 64-Channel Digital Output Module

Yes. The ADV569 is specified as a 64-channel digital output module compatible with ST7. When replacing an installed module, the channel count and ST7 compatibility should be checked together so the replacement matches the existing I/O architecture.

The output contact rating is 30 V DC and 100 mA for resistive or inductive loads. The actual field load should therefore be checked against the specified rating before replacement or commissioning.

The module uses a common-minus arrangement every 16 channels. Replacement planning should therefore consider the existing field wiring and channel grouping rather than checking only the model number.

The -P specification code denotes the pulse-width/time-proportional output function. The specified pulse width range is 8 ms to 7200 s, with 8 ms resolution and an additional maximum 1 ms for ON/OFF delay time.

The external connection is specified through a dedicated KS9 cable. For replacement planning, confirm the existing connection arrangement together with the ADV569-P00 model and ST7 compatibility.

The compatible ST-family range includes digital I/O modules such as ADV159, ADV559, ADV859, ADV169, ADV569 and ADV869. The correct selection depends on the required input/output function, channel count and isolation arrangement.
