The A2SAT105 is an mV / thermocouple / RTD input adaptor used in the Yokogawa N-IO architecture for RIO system upgrade applications. The A2SAT105-S000 is the standard, non-explosion-protection, basic configuration within the A2SAT105 suffix structure.
01 / ROLE
Analog Temperature Input
Designed for field-side mV, thermocouple and three-wire RTD measurement within the N-IO upgrade architecture.
▣ SYSTEM POSITION
The adaptor mounts on the A2BA3D I/O adaptor nest and connects to its terminals.
Between field and system: 1500 V AC for 1 minute, 42 V DC.
Current Consumption
24 V system supply: 12 mA or lower; 5 V internal supply: 10 mA or lower.
Burnout Detection
Selectable UP / DOWN / OFF; detection time 60 s or less; burnout detection current 0.1 μA.
Dimensions
Approx. 146.8 × 42.9 × 40 mm overall adaptor dimensions shown in the dimensional drawing.
Weight
Approx. 0.10 kg
SIGNAL COVERAGE
One Adaptor · Multiple Temperature Input Types
mV
−50 to 150 mV
Input resistance: 1 MΩ at power-on and 10 kΩ at power-off.
TC
J / K / E / B / R / S / T / N
Reference junction compensation is available with the dedicated RJC module arrangement.
RTD
3-wire · 0 to 400 Ω
Supports Pt100 and JPt100 configurations specified for the adaptor.
POT
100 to 2000 Ω total
Span resistance must be at least 50% of total resistance.
CONFIGURATION LOGIC
Built Around the N-IO Upgrade Path
A2SAT105 belongs to the N-IO I/O adaptor family used to connect field signals within a RIO system upgrade architecture. It is mounted on the A2BA3D nest and provides the interface for mV, thermocouple, RTD and potentiometer input applications.
For thermocouple applications using the M4 screw-terminal version of the A2BA3D, the S9393UK reference junction compensation module is required. The ELCO connector configuration provides mV input only.
MODEL CODE
A2SAT105-S000
-S
Standard type
0
No explosion protection
0
Basic type
0
Always 0
A2SAT105 FAMILY
Related Configuration Options
A2SAT105-S000
Standard · no explosion protection · basic type
A2SAT105-S100
Standard · ISA Standard G3 option
A2SAT105-S200
Standard · −40 to 70 °C option
A2SAT105-S300
Standard · ISA Standard G3 + temperature option
The suffix options are configuration distinctions within the A2SAT105 family; the exact installation environment and required options should be matched to the target N-IO arrangement.
PURCHASE & CONFIGURATION QUESTIONS
A2SAT105-S000 FAQ
01 · Can A2SAT105-S000 handle both thermocouple and RTD applications?
Yes. A2SAT105 is designed for mV, thermocouple, 3-wire RTD and 3-wire potentiometer inputs. The selected signal type and range are configured by software.
02 · Does A2SAT105-S000 require an RJC module for thermocouple input?
For thermocouple input on the A2BA3D M4 screw-terminal configuration, Yokogawa specifies the S9393UK reference junction compensation module. One module is required for each A2SAT105 used as thermocouple input.
03 · Is A2SAT105-S000 suitable when the installation needs a wide temperature option?
A2SAT105-S000 is the basic suffix configuration. The A2SAT105 family separately provides a temperature option for −40 to 70 °C. The required suffix should therefore be matched to the actual installation configuration rather than assuming the basic S000 code includes that option.
04 · Can A2SAT105-S000 be used with an ELCO connector configuration?
The ELCO connector configuration restricts A2SAT105 to mV input. Thermocouple use requires the M4 screw-terminal A2BA3D arrangement together with the specified reference junction compensation module.
05 · What should be checked before purchasing A2SAT105-S000 as a replacement?
Confirm the complete adaptor code, A2BA3D nest configuration, field signal type, connector arrangement and any required thermocouple reference-junction arrangement. For RIO upgrade installations, also verify the applicable N-IO hardware combination before replacement.
