Manufacturer |
Woodward |
|
Model |
5464-653 |
|
Descripution |
32 Channel Discrete Output Module |
|
Dimensions |
2.5x24.6x26.1cm |
|
Weight |
0.8kg |
Woodward ➟ USA ➟ 5464-648 ➟ Analog 8 Channel 4-20MA Output Module
CONDITION NEW ➟ IN STONCK
|
|
32 Channel Discrete Output Module |
Module Description
The MicroNet control can provide discrete outputs to the prime mover from field wiring. Each Discrete Output (DO) module can individually control 32 outputs according to commands from the CPU module. These modules have no potentiometers and require no calibration. A module may be replaced with another module of the same part number without any adjustment. There are two different FTM I/O configurations for the 32Ch DO Module. The module can be connected to one 32Ch Relay Module or two 16Ch Relay Modules.
Module Specification
|
Number of channels |
32 |
|
Update time |
5 ms |
|
Output Type |
Open drain drivers, intended for use with Woodward relay interface modules |
|
Fault Detection Read back |
Output channel status, relay status is not available |
|
System Faults |
Outputs are turned off if communications with the CPU is lost. |
Installation
The modules slide into card guides in the control's chassis and plug into the motherboard. The modules are held in place by two screws, one at the top and one at the bottom of the front panel. Also at the top and bottom of the module are two handles which, when toggled (pushed outward), move the modules out just far enough for the boards to disengage the motherboard connectors.
This module receives digital data from the CPU and generates 32 nonisolated relay driver signals. All discrete output modules in the system interface to one or more Woodward Relay Modules, each with 16 or 32 relays. The contacts of these relays then connect to the field wiring.
A separate 24 Vdc power source must be provided for the relays; this module does not furnish this power. A section of a multi-output Main Power Supply can be used, or power from a single-output Main Power Supply can be used, as long as sufficient current is available.
Each 32Ch DO Module is connected through one low density discrete cable to a 32Ch Relay module or a 16Ch Relay module daisy chained to a second 16Ch Relay module with another low density cable.
|
