TRICONEX 4701X

Overview Specifications Application FAQ Delivery Contact

TRICON CX / I/O BUS INTERFACE

4701X

I/O Bus Interface Module

Serial-Serial · IMSS · RS-485

The 4701X provides the serial I/O Bus interface for the Tricon CX I/O expansion architecture. It connects the I/O Bus through RJ-45 copper interfaces and supports the TMR communication structure used by the Tricon CX platform.

RS-485

RJ-45

TMR I/O BUS

TRICON CX

SYSTEM POSITION

8131X
I/O Expansion Chassis

4701X
IMSS

Leg A

Leg B

Leg C

Serial I/O Bus connection through industrial RJ-45 copper cabling.

TECHNICAL CORE

4701X

A compact serial interface designed to connect the Tricon CX I/O Bus within the I/O expansion architecture.

Interface

RS-485 serial I/O Bus communication with RJ-45 copper input and output ports.

Bus Distance

Supports I/O Bus distances up to 100 ft (30 m).

Logic Power

Logic power consumption is less than 1 watt.

STATUS INDICATORS

Pass

Fault

Alarm

Power 1

Power 2

FIELD APPLICATION

When the I/O Bus
must stay connected

The 4701X belongs in the Tricon CX I/O expansion path where serial I/O Bus communication is required between the 8131X I/O Expansion Chassis and the connected TMR I/O Bus architecture.

Typical search trigger A replacement search can arise when the existing 4701X shows a fault condition, loses normal I/O Bus communication, or when a maintenance team needs an exact spare for an installed Tricon CX expansion chassis.	Why the part matters An interface fault can interrupt the communication path between the I/O expansion chassis and its I/O Bus. In a safety-related installation, unresolved communication or module faults can therefore increase maintenance urgency and potentially affect process availability.
Installation perspective: The 4701X uses RJ-45 copper I/O Bus connections and is specified for distances up to 30 m. For TMR I/O Bus security, the Tricon CX architecture uses three independent physical networks for the A, B and C legs.

TRICON CX FAMILY Related Architecture

8120X
Main Chassis

8131X
I/O Expansion Chassis

4701X
I/O Bus Interface · RS-485

4703X
I/O Bus Interface · Fiber

3009X
Main Processor

Tricon CX communication and I/O architecture includes serial and fiber I/O Bus interface options.

PURCHASE QUESTIONS

4701X FAQ

Q1 · Is TRICONEX 4701X the correct replacement for a serial I/O Bus connection?

Yes, when the installed architecture requires the Tricon CX 4701X IMSS with RS-485 serial I/O Bus communication. It should be matched against the existing chassis and system configuration before ordering.

Q2 · Why would a TRICONEX 4701X fault require an urgent spare?

Because the module forms part of the I/O Bus communication path in an I/O expansion chassis. A persistent interface fault can prevent normal communication with the associated I/O architecture and can increase troubleshooting and process-availability risk.

Q3 · What cable distance should be considered when purchasing a TRICONEX 4701X?

The specified I/O Bus distance for the 4701X serial interface is up to 100 ft (30 m). Industrial CAT 6 cable is specified for the I/O Bus connection.

Q4 · Should I choose TRICONEX 4701X or 4703X for a Tricon CX expansion?

The choice depends on the physical I/O Bus medium. The 4701X is the serial RS-485 RJ-45 interface, while the 4703X is the fiber-fiber interface. Existing system topology and cable infrastructure should determine the replacement.

Q5 · What should I check before ordering a TRICONEX 4701X replacement?

Confirm the exact part number, installed Tricon CX chassis, I/O Bus interface type, required quantity, destination and required replacement date. For urgent cases, provide the machine or system application so the correct configuration can be checked before shipment.
