6ES7288-5DT04-0AA0Digital I/O Signal Board — SB DT04
The Siemens 6ES7288-5DT04-0AA0 is a SIMATIC S7-200 SMART SB DT04 digital signal board providing 2 digital inputs and 2 digital outputs. The board is designed for compact S7-200 SMART control architectures where a small amount of additional digital I/O is required.
|
PRODUCT IDENTIFICATION
6ES7288-5DT04-0AA0
|
|
01
Compact I/O Expansion
Adds a small digital I/O increment to an S7-200 SMART CPU. |
02
24 V DC Signals
Provides two 24 V DC digital input channels and two digital output channels. |
03
Fast Signal Response
Input delay is specified at up to 20 µs, with output delay of 2 µs / 10 µs. |
04
Status Indication
LED indication is provided for input and output status. |
| Product type designation | SB DT04, DI 2 × 24 V DC, DQ 2 × 24 V DC / 0.75 A |
| Digital inputs | 2 |
| Digital outputs | 2 |
| Rated supply voltage | 24 V DC |
| Permissible supply range | 20.4 to 28.8 V DC |
| Typical current consumption | 50 mA |
| Typical power loss | 1 W |
| Input signal "0" | Maximum 5 V |
| Input signal "1" | Minimum 15 V |
| Input current at signal "1" | Typical 2.5 mA |
| Input current at signal "0" | Maximum 1 mA |
| Input delay | Maximum 20 µs, 0 → 1 and 1 → 0 |
| Shielded cable length | Maximum 500 m |
| Unshielded cable length | Maximum 300 m |
| Digital output rating | 24 V DC / 0.75 A |
| Output short-circuit protection | No |
| Output delay, 0 → 1 | Maximum 2 µs |
| Output delay, 1 → 0 | Maximum 10 µs |
| Input status LED | Yes |
| Output status LED | Yes |
| Protection rating | IP20 |
| CE mark | Yes |
| Width | 35 mm |
| Height | 52.2 mm |
| Depth | 16 mm |
| Approx. weight | 18.1 g |
|
DELIVERY
3–5 Days
Fast quotation and order coordination
|
WARRANTY
12 Months
Product warranty support
|
PACKAGING
Brand New
Carefully prepared for shipment
|
|
Dedicated Multilingual Support Team
Our team coordinates product identification, quotation details, order communication and international delivery requirements.
|
Automation Parts Supply
We support customers searching for industrial automation components and hard-to-source replacement parts with coordinated order handling.
|
|
01 · Compact S7-200 SMART Systems
The SB DT04 belongs to the SIMATIC S7-200 SMART signal-board family. It is intended for applications where the CPU requires a small additional amount of digital I/O without using a larger expansion arrangement. |
02 · 24 V DC Field Signals
The board provides two 24 V DC digital inputs and two 24 V DC digital outputs, making it suitable for compact machine-control signal requirements. |
|
03 · Typical Troubleshooting Search
During maintenance, this part number may be checked when a configured 24 V digital input does not register correctly, when a configured output does not switch as expected, or when an existing SB DT04 needs replacement. |
04 · Downtime Consideration
If a machine sequence depends on one of these digital points, loss of the associated signal can interrupt an interlock, command or process step. Because the outputs are specified without short-circuit protection, field wiring should be checked carefully during troubleshooting. |
It provides 2 digital inputs and 2 digital outputs. The inputs are specified for 24 V DC signals, while the outputs are 24 V DC transistor outputs rated at 0.75 A.
The rated supply voltage is 24 V DC, with a permissible range from 20.4 V to 28.8 V DC.
The specified input delay is up to 20 µs for both transitions. For the digital outputs, the specified delay is up to 2 µs from 0 to 1 and 10 µs from 1 to 0.
Yes. The SB DT04 provides LED indication for input status and output status, which can assist technicians when checking the state of field signals.
The Siemens specification identifies the digital outputs as having no short-circuit protection. Field wiring and connected loads should therefore be checked carefully during commissioning and maintenance.
